Circuit breaker Edimax DP-150W54V 2.8 A 90-264 V DIN-rail Black

The Edimax DP-150W54V circuit breaker is a DIN-rail mount electrical protection device engineered for compact installations. It accepts an AC input voltage range of 90–264 V at 47–63 Hz and provides overcurrent protection with a rated maximum current of 2.8 A. The unit is finished in black and designed to fit standard DIN-rail environments where space efficiency and regulatory compliance are required. CE and FCC certifications indicate conformity with relevant safety and electromagnetic standards.

Advantages

The Edimax DP-150W54V combines a narrow housing profile with reliable overcurrent interruption, making it suitable for installations with limited panel space. Its broad input voltage range supports usage in systems with variable mains conditions. The compact dimensions (116 mm width, 122 mm depth, 40 mm height) facilitate mounting in dense control cabinets or modular distribution assemblies. CE and FCC compliance supports safe deployment in commercial and industrial settings.

Suitable for

• DIN-rail mounted power distribution boards in industrial control panels
• Protection of low-current devices and circuits up to 2.8 A
• Applications with wide AC mains voltage variation (90–264 V)
• Compact electrical enclosures and network equipment racks

Key specifications

• Maximum current rating: 2.8 A
• Input voltage range: 90–264 V AC
• Input frequency: 47–63 Hz
• Mounting: DIN-rail
• Dimensions (W × D × H): 116 mm × 122 mm × 40 mm
• Color: Black
• Certifications: CE, FCC

How to use

Mount the circuit breaker on a standard DIN-rail inside the intended electrical cabinet or distribution panel, ensuring secure mechanical engagement. Connect the AC supply conductors to the appropriate input terminals and route the protected load on the output side according to the panel wiring diagram. Verify the input voltage falls within the specified 90–264 V AC and confirm the connected load does not exceed 2.8 A. After wiring, perform functional checks and restore power, observing device operation and system indicators where applicable.

Recommendations

Install the device in a dry, ventilated panel away from heat sources and corrosive environments. Use appropriate wire sizes and terminal torque values per applicable wiring standards. For circuit protection selectivity, coordinate this breaker with upstream and downstream protection devices. Follow local electrical codes and qualified personnel procedures during installation and maintenance.
