Chint | Circuit breaker RCBO, NB310L/3N, 3P+N, C20, 30mA, A, 6kA | NB310L3PN30MAA20C

Chint | Circuit breaker RCBO, NB310L/3N, 3P+N, C20, 30mA, A, 6kA | NB310L3PN30MAA20C
Chint | Circuit breaker RCBO, NB310L/3N, 3P+N, C20, 30mA, A, 6kA | NB310L3PN30MAA20C
Chint | Circuit breaker RCBO, NB310L/3N, 3P+N, C20, 30mA, A, 6kA | NB310L3PN30MAA20C
Chint | Circuit breaker RCBO, NB310L/3N, 3P+N, C20, 30mA, A, 6kA | NB310L3PN30MAA20C
Chint | Circuit breaker RCBO, NB310L/3N, 3P+N, C20, 30mA, A, 6kA | NB310L3PN30MAA20C
Chint | Circuit breaker RCBO, NB310L/3N, 3P+N, C20, 30mA, A, 6kA | NB310L3PN30MAA20C
R1,657
The CHINT NB310L/3N RCBO is a compact residual current circuit breaker with overcurrent protection, designed for three-phase applications. This 3P+N unit combines a C20 curve thermal-magnetic breaker with a 30mA Type A residual current device, offering reliable protection against both overloads, sho... Read More
Stock 5 Code 1517412 Brand CHINT Model NB310L3PN30MAA20C Warranty 2 Years

Shipping & Returns

Estimated delivery Monday, October 5
You will be kept updated through our detailed tracking system
Payment options
EFTPayFastBank CardSnapScanZapperGoogle PayApple PayMobicredMoreTymePay on Arrival

The CHINT NB310L/3N RCBO is a compact residual current circuit breaker with overcurrent protection, designed for three-phase applications. This 3P+N unit combines a C20 curve thermal-magnetic breaker with a 30mA Type A residual current device, offering reliable protection against both overloads, short circuits, and earth faults in residential and commercial electrical installations.

Key features

  • Rated current: 20A (C-curve) for standard overcurrent and short-circuit protection
  • Residual sensitivity: 30mA Type A, detecting AC and pulsating DC fault currents
  • Breaking capacity: 6kA, suitable for most low-voltage distribution boards
  • Pole configuration: 3P+N, protecting three phases and switching the neutral
  • Compact dimensions: 95mm width, 85mm height, 77mm depth for space-saving installation
  • Net weight: 0.27 kg, facilitating easy handling and mounting
  • Manufacturer warranty: 24 months, ensuring long-term reliability
Specifications
Brand
Chint
Category
Circuit Breakers
EAN
6925808357672
Embeeded battery
No
Gross depth (mm)
77.00
Gross height (mm)
85.00
Gross weight
0.46
Gross width (mm)
95.00
Material
Plastic
Model
NB310L3PN30MAA20C
MPN
NB310L3PN30MAA20C
Net weight
0.27
Packing quantity
1.00
Palette Qty
2174
Paper/Pasteboard
192.00
Plastic (No PET)
40.00
Producer
Chint
Producer product family
Circuit breaker RCBO, NB310L/3N, 3P+N, C20, 30mA, A, 6kA
Producer product name
NB310L3PN30MAA20C
Product type
Battery
Tare weight (kg)
0.19
TI weight (kg)
0.03
Volume (m3)
0.00
Warranty
24
WEE classification
CL109:6:2017-04-01
WEEE tax
No
