CABLETECH Coaxial Cable F690 BV 75 Ohm Black

Coaxial cable engineered for reliable signal transmission with a robust double-shielded design. The F690 BV delivers a stable 75 Ohm impedance across a wide frequency range, making it a dependable choice for TV, satellite, and broadband installations. Its copper-clad steel inner conductor and foamed polyethylene dielectric ensure consistent performance and durability in both indoor and outdoor environments.

Advantages

Double shielding (aluminium foil plus 60% coverage aluminium braid) provides excellent screening effectiveness of over 75 dB, protecting signals from electromagnetic interference. The black PVC jacket is UV-resistant and suitable for temperatures from -20°C to +70°C, ensuring long-term reliability. Low attenuation values (5.0 dB/100m at 50 MHz, 20.0 dB/100m at 860 MHz, 32.0 dB/100m at 2150 MHz) maintain signal strength over long cable runs. The 1.0 mm copper-clad steel conductor offers a good balance of conductivity and tensile strength, while the 4.8 mm foamed polyethylene dielectric minimizes signal loss.

Suitable for

• Connecting satellite dishes and antennas to receivers
• Distributing cable TV signals within buildings
• Broadband internet and data network installations
• Professional audio/video systems requiring 75 Ohm coaxial cable
• Outdoor and indoor applications where shielding is critical

Key specifications

• Impedance: 75 Ohm
• Cable type: Coaxial
• Inner conductor: Copper Clad Steel (CCS), 1.0 mm diameter
• Dielectric: Foamed Polyethylene (FPE), 4.8 mm diameter
• Shielding: Aluminium foil + aluminium braid (60% coverage)
• Outer jacket: PVC, black, 6.8 mm outer diameter
• Attenuation: 5.0 dB/100m @ 50 MHz, 20.0 dB/100m @ 860 MHz, 32.0 dB/100m @ 2150 MHz
• Screening effectiveness: >75 dB (30-1000 MHz)
• Return loss: >20 dB (5-1000 MHz)
• Operating temperature: -20°C to +70°C
• No connectors included (bare cable)

Recommendations

For best results, pair with high-quality F-type compression connectors and use proper stripping tools to maintain shielding integrity. Avoid tight bends below the minimum bend radius to prevent signal degradation. This cable is ideal for installers and DIY enthusiasts who need a reliable, high-performance coaxial solution.
