BlueOptics TXP1XGDS2X-BO network transceiver module Fiber optic 10000 Mbit/s XFP 1310 nm

The BlueOptics TXP1XGDS2X-BO network transceiver module is a 10G XFP optical transceiver designed for single-mode fiber links operating at a wavelength of 1310 nm. It supports a maximum data transfer rate of 10000 Mbit/s, uses an XFP interface and is housed in a robust metal enclosure. The module is compact and lightweight (approx. 20 g) and is powered from a 3.3 V input, making it suitable for integration into networking equipment that accepts XFP form-factor transceivers.

Advantages

The transceiver delivers standardized XFP connectivity for 10G applications and is compatible with systems supporting 10GBASE-LR operation over single-mode fiber. Its metal housing provides mechanical stability and thermal dissipation while the defined 1310 nm wavelength supports reliable long-reach optical transmission. The lightweight design and common 3.3 V supply facilitate installation and replacement in racks, switches, routers and other networking platforms.

Suitable for

Key specifications

How to use

Install the BlueOptics TXP1XGDS2X-BO into an available XFP slot of a compatible network device following the device manufacturer's hot-swap or installation procedure. Connect an LC duplex single-mode patch cable to the transceiver and to the remote transceiver or patch panel. Ensure the host device is configured for 10G operation and that port settings match the intended protocol (for example, 10G Ethernet). Observe ESD precautions when handling the module and remove protective dust caps from fiber connectors before insertion to avoid contamination.

Recommendations

Verify host compatibility before installation and confirm that the network equipment supports the XFP transceiver and any digital diagnostic features you intend to use. Use clean single-mode LC duplex patch cords and appropriate fiber management to maintain signal quality. If monitoring is required, enable any supported digital diagnostic monitoring (DDM/DOM) features in the host system to track supply voltage, optical power and temperature.
