BlueOptics FTLF1519P1xCL Compatible SFP+ Transceiver 10GBASE-LR 10 km LC SMF BO05C15680D

The BlueOptics FTLF1519P1xCL compatible SFP+ transceiver (BO05C15680D) is a high-performance, cost-effective optical module designed for 10 Gigabit Ethernet applications. It is fully compliant with the SFP+ MSA and is compatible with Finisar FTLF1519P1xCL series transceivers, ensuring seamless integration into existing network infrastructure.

Advantages

This transceiver offers reliable 10 Gbps connectivity over single-mode fiber at distances up to 10 km. With low power consumption (<1W) and hot-pluggable capability, it simplifies network upgrades and maintenance. The built-in digital diagnostics monitoring (DDM/DOM) provides real-time performance data for proactive network management.

Suitable for

• 10 Gigabit Ethernet networks (10GBASE-LR)
• Data center interconnects
• Enterprise LAN and WAN applications
• Telecommunications and service provider networks

Key specifications

• Module Type: SFP+ Transceiver
• Data Rate: 10 Gbps
• Protocol: 10GBASE-LR
• Wavelength: 1310 nm
• Max Reach: 10 km
• Fiber Type: Single-Mode Fiber (SMF)
• Connector Type: LC Duplex
• DDM/DOM Support: Yes
• Compatibility: Finisar FTLF1519P1xCL compatible, MSA Compliant
• Hot-Pluggable: Yes
• Transmitter Type: DFB Laser
• Receiver Type: PIN Photodiode
• Power Consumption: < 1W
• Operating Temperature: 0°C to 70°C
• Compliance: RoHS, CE, FCC

Recommendations

For optimal performance, use with single-mode fiber patch cables (OS2) and ensure proper handling to avoid damage to the optical ports. This transceiver is ideal for upgrading existing 1 Gbps links to 10 Gbps without replacing the entire fiber infrastructure.
