BlueOptics FTLF1323P1xTL Compatible SFP Transceiver BO05A13602 - 1.25 Gbps 850 nm 550 m MMF LC

The BlueOptics FTLF1323P1xTL compatible SFP transceiver (BO05A13602) is a high-performance, cost-effective optical module designed for 1000Base-SX Ethernet applications. It operates at a data rate of 1.25 Gbps over multi-mode fiber (MMF) with a wavelength of 850 nm, supporting distances up to 550 m. This hot-pluggable SFP transceiver features an LC duplex connector and is fully compliant with MSA standards, ensuring seamless integration into a wide range of networking equipment.

Advantages

This transceiver offers reliable performance with low power consumption (<1W) and supports Digital Diagnostic Monitoring (DDM) for real-time monitoring of operating parameters. It is a direct replacement for Finisar FTLF1323P1xTL modules, providing identical functionality at a competitive price point. The VCSEL transmitter and PIN receiver ensure stable optical performance over the specified temperature range (0°C to 70°C).

Suitable for

• Gigabit Ethernet networks requiring 1000Base-SX connectivity
• Data center and enterprise network uplinks
• Fiber optic connections over multi-mode fiber up to 550 m
• Replacement or expansion of existing SFP-based systems

Key specifications

• Form Factor: SFP
• Data Rate: 1.25 Gbps
• Ethernet Standard: 1000Base-SX
• Wavelength: 850 nm
• Max Transmission Distance: 550 m
• Fiber Type: Multi-mode Fiber (MMF)
• Connector Type: LC Duplex
• DDM/DOM Support: Yes
• Operating Temperature: 0°C to 70°C
• Power Consumption: < 1W
• Hot-Pluggable: Yes
• Compliance: MSA Compliant, RoHS

Recommendations

For optimal performance, use with high-quality multi-mode fiber (OM2/OM3/OM4) and ensure proper handling of LC connectors. This transceiver is ideal for network upgrades or new installations requiring reliable Gigabit Ethernet connectivity.
