AXING BVE 8-02 8-Way F-Type Splitter 5-2400 MHz, 75 Ohm, Die-Cast Zinc Housing

Distribute a single satellite or cable signal to eight outputs with the AXING BVE 8-02, a high-performance F-type splitter engineered for uncompromising signal integrity. Covering an exceptional frequency range from 5 to 2400 MHz, this robust splitter handles SAT, CATV, DVB-T/T2, and radio signals with minimal insertion loss and excellent isolation.

Overview

The AXING BVE 8-02 is a professional-grade signal distributor built for demanding installations. Its die-cast zinc housing ensures durability and effective shielding (Class A per EN 50083-2), while the F-connector interface provides secure, reliable connections. With DC pass on all outputs (up to 500 mA), it can power connected amplifiers or active antennas directly through the splitter, simplifying system design.

What stands out

• Wide frequency range: 5–2400 MHz covers all current broadcast and satellite bands.
• Low insertion loss: from 11.5 dB (5–40 MHz) to 14.0 dB (1750–2400 MHz) ensures strong signal delivery.
• High isolation between outputs: >18 dB prevents signal interference.
• DC pass on all outputs: up to 500 mA for powering remote devices.
• Die-cast zinc housing with Class A shielding for superior EMI protection.

Technical details

• Product Type: F-Splitter / Signal Distributor
• Number of Inputs: 1
• Number of Outputs: 8
• Frequency Range: 5 - 2400 MHz
• Connector Type: F-connector
• Impedance: 75 Ohm
• Insertion Loss (5-40 MHz): ~11.5 dB
• Insertion Loss (40-450 MHz): ~12.0 dB
• Insertion Loss (450-860 MHz): ~12.5 dB
• Insertion Loss (950-1750 MHz): ~13.0 dB
• Insertion Loss (1750-2400 MHz): ~14.0 dB
• Isolation between Outputs (5-2400 MHz): >18 dB
• Return Loss (5-2400 MHz): >8 dB
• DC Pass: Yes, on all outputs
• Max DC Current: 500 mA
• Shielding Class: Class A (EN 50083-2)
• Housing Material: Die-cast zinc
• Application: Satellite (SAT), Cable TV (CATV), DVB-T/T2, Radio

Our verdict

The AXING BVE 8-02 is a reliable and versatile splitter that delivers consistent performance across a broad spectrum. Its robust construction and DC pass capability make it an excellent choice for both residential and commercial signal distribution.
