ATTE IPP-1-20-HS Signal Line Surge Protector, 1 Channel, 12V DC/24V AC, 5kA, Screw Terminal

The ATTE IPP-1-20-HS is a high-performance signal line surge protector designed to safeguard sensitive electronic equipment from transient overvoltages. With a single protected channel, it is ideal for use in CCTV, access control, and industrial automation systems. The device offers reliable protection for video, data, and control signal lines, ensuring uninterrupted operation and extended equipment life.

Advantages

This surge protector features ultra-fast response time (<1 ns) and low insertion loss (<0.2 dB), making it suitable for high-speed data applications without signal degradation. Its robust design includes screw terminals for easy installation and a separate ground connection for optimal safety. The compact ABS housing allows for screw mounting in various environments.

Suitable for

• CCTV systems
• Access control systems
• Industrial automation equipment
• Video and data signal lines
• Control signal protection

Key specifications

• Product Type: Signal Line Surge Protector
• Number of Channels: 1
• Nominal Voltage (Un): 12V DC / 24V AC
• Max Continuous Operating Voltage (Uc): 30V DC / 24V AC
• Nominal Discharge Current (In): 5 kA (8/20µs)
• Max Discharge Current (Imax): 10 kA (8/20µs)
• Voltage Protection Level (Up) Line-Line: ≤ 60 V
• Voltage Protection Level (Up) Line-Ground: ≤ 600 V
• Response Time: < 1 ns
• Insertion Loss: < 0.2 dB
• Bandwidth: Up to 100 MHz
• Connectors: Screw Terminals (IN/OUT, Ground)
• Mounting Type: Screw Mount
• Housing Material: ABS Plastic
• Operating Temperature: -25°C to +55°C
• Protection Mode: Line-Line, Line-Ground

Recommendations

For optimal protection, install this surge protector as close as possible to the equipment being protected. Ensure proper grounding according to local electrical codes. Suitable for indoor use only.
