ATEN CL5716M 16-Port LCD KVM Rack Console

ATEN CL5716M 16-Port LCD KVM Rack Console
ATEN CL5716M 16-Port LCD KVM Rack Console
ATEN CL5716M 16-Port LCD KVM Rack Console
ATEN CL5716M 16-Port LCD KVM Rack Console
ATEN CL5716M 16-Port LCD KVM Rack Console
ATEN CL5716M 16-Port LCD KVM Rack Console
R29,018
ATEN CL5716M Slideaway LCD KVM rack console with integrated LCD monitor, keyboard, touchpad and 16-port KVM switch for rack server control.... Read More
Stock 3 Code 2194174 Brand ATEN Model DCP3019 Warranty 2 Years

Shipping & Returns

Estimated delivery Tuesday, October 6
You will be kept updated through our detailed tracking system
Payment options
EFTPayFastBank CardSnapScanZapperGoogle PayApple PayMobicredMoreTymePay on Arrival
ATEN CL5716M Slideaway LCD KVM rack console with integrated LCD monitor, keyboard, touchpad and 16-port KVM switch for rack server control.
Key Highlights
  • Server rooms and small data centers managing up to 16 servers
  • IT racks where space-saving integrated console is required
  • Mixed environments with PS/2 and USB systems
  • Setups that require centralized access and multi-system monitoring
  • Brand: ATEN
  • Model / MPN: CL5716M
  • Ports: 16 KVM ports
  • Console: Integrated 17" LCD monitor
  • Supported resolutions: up to 1280 x 1024 @ 75 Hz
  • Interfaces: Dual interface (USB and PS/2) for keyboard and mouse
  • Peripheral: USB port on LCD module for USB devices
  • Daisy-chain: Supports chaining additional units to control up to 512 computers (with compatible models)
  • Security: Two-level password protection (1 admin + 4 users)
  • Weight: 14 kg
  • Colour: Black
Specifications
Built-in display
Yes
Console ports
USB A, VGA (D-Sub)
Console USB ports quantity
1
Daisy chain
Yes
DDC2B support
Yes
Depth
642.7 mm
Display
LCD
Display diagonal
43.2 cm (17")
Firmware upgradeable
Yes
HD type
SXGA
HDCP
Yes
Height
44 mm
Hot keys
Yes
Hot-Plug support
Yes
Housing material
Metal, Plastic
Input current
1 A
Input voltage
100-240 V
Keyboard language
Chinese Traditional, French, German, Greek, Italian, Japanese, Korean, Russian, Spanish, Swedish, Swiss, UK English, US English
Keyboard port type
USB, PS/2
LED indicators
Yes
Linux operating systems supported
Yes
Mac operating systems supported
Yes
Maximum resolution
1280 x 1024 pixels
Mouse port type
USB, PS/2
Number of computers controlled
512
Number of users
5 user(s)
On Screen Display (OSD)
Yes
Operating relative humidity (H-H)
0 - 80%
Operating temperature (T-T)
0 - 50 °C
Other operating systems supported
Yes
Power consumption (typical)
27.5 W
Power source
AC
Product colour
Black
PS/2 ports quantity
0
Push button
Yes
Rack capacity
1U
Rack mounting
Yes
Scan interval
1,255 s
Storage temperature (T-T)
-20 - 60 °C
USB connector type
USB Type-A
VGA (D-Sub) ports quantity
1
Video bandwidth
75 Hz
Video port type
VGA
Weight
13.6 kg
Width
480 mm
Windows operating systems supported
Yes

PDF

Open PDF

Document

Open Document

Leaflet

Open Leaflet
