ALLNET ALL-BRICK-0553 PoE Load Resistor 25 Ohm 25W RJ45 Black

The ALLNET ALL-BRICK-0553 is a professional PoE load resistor designed for testing and verifying Power over Ethernet (PoE) power supplies and switches. With a resistance of 25 Ohm and a power dissipation of 25W, it provides a reliable passive load for PoE applications. The compact plastic housing and RJ45 connector make it easy to integrate into any testing setup.

Advantages

This PoE load resistor offers plug-and-play operation, eliminating the need for complex configurations. Its compact design allows for easy portability and use in tight spaces. The device supports IEEE 802.3af (PoE) and IEEE 802.3at (PoE+) standards, making it versatile for various testing scenarios. The black color and durable plastic housing ensure long-lasting performance.

Suitable for

• Network technicians and engineers testing PoE switches and injectors
• Quality assurance labs verifying PoE power supply output
• Field service personnel troubleshooting PoE installations
• Educational institutions demonstrating PoE technology

Key specifications

• Product Type: PoE Load Resistor
• Resistance Value: 25 Ohm
• Power Dissipation: 25 W
• Connector Type: RJ45
• Supported PoE Standards: IEEE 802.3af (PoE), IEEE 802.3at (PoE+)
• Input Voltage (Max): 57 V DC
• Interface: 1x RJ45 (Input)
• Housing Material: Plastic
• Color: Black
• Operating Temperature: 0°C to 50°C
• Storage Temperature: -20°C to 70°C
• Operating Humidity: 10% to 90% non-condensing
• Features: Passive Load, Plug & Play, Compact Design
• Compliance: CE, RoHS
• Current Draw (at 48V): 1.92 A

Recommendations

For comprehensive PoE testing, pair the ALL-BRICK-0553 with a PoE power meter and a variety of powered devices. Ensure the load resistor is connected to a PoE source that can supply at least 25W. Always follow safety guidelines when working with electrical equipment.
