ALLNET ALL-BRICK-0536 300W 50 Ohm RF Dummy Load N-Type Male DC-1GHz

The ALLNET ALL-BRICK-0536 is a high-power RF dummy load / termination resistor designed for professional RF system testing, transmitter load, and power meter calibration. With a continuous power rating of 300W and a frequency range from DC to 1 GHz, it provides reliable and accurate termination for RF signals. The N-Type male connector ensures secure connection, while the integrated heat sink allows for convection cooling. Housed in a durable aluminum alloy enclosure, this dummy load is built for demanding environments.

Advantages

High power handling up to 300W continuous, low VSWR ≤1.2:1 across the entire frequency range, and robust aluminum construction ensure long-lasting performance. The compact design (100 x 60 x 30 mm) and lightweight (0.6 kg) make it easy to integrate into test setups.

Suitable for

• RF system testing and development
• Transmitter dummy load for maintenance
• Power meter calibration
• Laboratory and field applications

Key specifications

• Impedance: 50 Ohm
• Power Rating: 300 W (continuous)
• Frequency Range: DC to 1 GHz
• VSWR: ≤ 1.2:1
• Connector: N-Type Male
• Resistance Tolerance: ±5%
• Cooling: Convection (integrated heat sink)
• Housing Material: Aluminum Alloy
• Operating Temperature: -25°C to +55°C
• Max Input Voltage (RMS): 122.4 V
• Dimensions: 100 x 60 x 30 mm
• Weight: 0.6 kg
• Color: Black / Silver

Recommendations

For optimal performance, ensure proper ventilation for convection cooling. This dummy load is ideal for testing transmitters up to 300W and for use in 50 Ohm RF systems.
