ALLNET ALL-BRICK-0516 Resistor 5.6 Ohm 16 W Wirewound Axial

The ALLNET ALL-BRICK-0516 is a high-quality wirewound resistor designed for through-hole mounting. With a resistance value of 5.6 Ohm and a power rating of 16 W, it is ideal for various electronic applications requiring precise current limiting or voltage division. The resistor features a ceramic brick case style with axial leads, ensuring reliable performance and easy integration into circuit boards.

Advantages

This resistor offers excellent stability and durability thanks to its wirewound construction and ceramic core. It operates over a wide temperature range from -55°C to +155°C and has a low temperature coefficient of ±200 ppm/°C, ensuring consistent performance under varying conditions. The axial lead design simplifies manual and automated assembly processes.

Suitable for

• Power supplies and voltage regulators
• Motor control circuits
• Industrial automation equipment
• Audio amplifiers and test equipment
• General purpose current limiting and snubber circuits

Key specifications

• Resistance: 5.6 Ohm
• Power Rating: 16 W
• Tolerance: ±5%
• Mounting Type: Through Hole
• Resistor Type: Wirewound
• Temperature Coefficient: ±200 ppm/°C
• Operating Temperature: -55°C to +155°C
• Number of Terminals: 2
• Terminal Type: Axial Leads
• Dielectric Material: Ceramic
• Case Style: Brick
• Maximum Working Voltage: 250 V
• Insulation Resistance: >100 MΩ (at 500VDC)
• Dielectric Strength: 1500 VAC
• Lead Material: Tinned Copper
• Lead Diameter: 0.8 mm
• RoHS Compliant

Recommendations

For optimal performance, ensure proper heat dissipation by mounting the resistor with adequate spacing and ventilation. Verify that the operating voltage and power do not exceed the specified limits. This component is suitable for both prototyping and production runs.
