ALLNET ALL-BRICK-0507 5 Ohm 75W Wirewound Resistor Chassis Mount Screw Terminals

The ALLNET ALL-BRICK-0507 is a high-power wirewound resistor designed for industrial applications requiring reliable performance and robust construction. With a resistance value of 5 Ohm and a power rating of 75 W, this resistor is ideal for use as a braking resistor or load resistor in various electronic and electrical systems.

Advantages

Built with a ceramic housing and screw terminals, the ALL-BRICK-0507 offers excellent heat dissipation and secure connections. Its chassis mount design ensures easy installation and stable operation even in demanding environments. The resistor features a tolerance of ±5% and a temperature coefficient of ±200 ppm/°C, providing consistent performance across a wide temperature range.

Suitable for

• Industrial power supplies and motor drives
• Braking systems and dynamic braking resistors
• Load testing and dummy load applications
• Power electronics and inverter systems

Key specifications

• Resistance: 5 Ohm
• Power Rating: 75 W
• Tolerance: ±5%
• Type: Wirewound
• Housing Material: Ceramic
• Mounting: Chassis Mount
• Termination: Screw Terminals
• Temperature Coefficient: ±200 ppm/°C
• Operating Temperature: -55°C to +155°C
• Dielectric Strength: 2.5 kV AC
• Insulation Resistance: >100 MΩ
• Overload Capacity: 1.5 x rated power for 5s
• Number of Terminals: 2
• Series: ALL-BRICK
• Product Line: Industrial Power Resistors

Recommendations

For optimal performance, ensure proper heat sinking and follow the manufacturer's mounting instructions. This resistor is suitable for continuous operation at rated power with adequate ventilation.
