Air cooler Noctua NH-D15 G2 HBC, dual 140 mm fans, 1250–1500 RPM, 155.6 m³/h, 12 V, copper, 152×150×168 mm

The Noctua NH-D15 G2 HBC is a high-performance dual-tower air cooler designed for demanding desktop CPUs. It features two next-generation NF-A14x25r G2 140 mm PWM fans with speed-offset operation, eight heatpipes, asymmetrical fin-stacks tuned for improved airflow, and a specialised High Base Convexity (HBC) base to ensure optimal contact on strongly concave processors such as some Intel LGA1700 units. The cooler includes Noctua’s SecuFirm2+™ Torx-based multi-socket mounting system, NT-H2 thermal compound and accessories, and is backed by a 6-year manufacturer’s warranty.

Advantages

The NH-D15 G2 HBC delivers improved quiet cooling performance compared to the previous NH-D15 through optimised fin spacing, increased fin surface area and the use of two NF-A14x25r G2 fans. Eight heatpipes increase thermal capacity at high loads, while the speed-offset fans and PWM control provide a wide speed range from 1500 rpm down to 300 rpm and allow semi-passive operation when set to 0% PWM. The offset heatsink design improves clearance for the top PCIe x16 slot on most motherboards, and recessed lower fins enable high RAM compatibility in single-fan mode. The heatsink fins are soldered to the heatpipes to ensure long-term thermal reliability.

Suitable for

• High-performance desktop CPUs with elevated heat loads (e.g., heavy multithreaded workloads and overclocking)
• Intel LGA1700 processors that exhibit concave deformation or are used with full ILM pressure
• Systems requiring excellent component airflow over VRMs and motherboard heatsinks
• Builds that need good top PCIe x16 slot clearance on most modern motherboards

Key specifications

• Type: Air cooler
• Model: Noctua NH-D15 G2 HBC (High Base Convexity variant)
• Fans: 2× NF-A14x25r G2 PWM, 140 mm, PWM 300–1500 rpm (with Low-Noise Adaptors reducing max to 1300 rpm)
• Airflow (per product summary): 155.6 m³/h
• Heatpipes: 8 soldered heatpipes
• Dimensions (heatsink): approx. 150 mm (W) × 152 mm (D) × 168 mm (H) including fans (manufacturer-stated overall height)
• Weight: 1.525 kg
• Supported sockets: Intel LGA1700, LGA1200, LGA115x; AMD AM5, AM4 (plus optional legacy kits for older sockets)
• Included accessories: SecuFirm2+™ mounting kit, NM-SD1 screwdriver, NT-H2 thermal compound, NA-TPG1 thermal paste guard, Low-Noise Adaptors
• Warranty: 6-year manufacturer’s warranty

How to use

Install the NH-D15 G2 HBC using the supplied SecuFirm2+™ Torx-based mounting system following the included manual for your socket. Apply a pea-sized amount of the included NT-H2 thermal compound to the CPU heatspreader, mount the heatsink and secure the screws with the provided NM-SD1 screwdriver. Choose single- or dual-fan configuration depending on RAM clearance: single-fan mode provides at least 59 mm clearance for tall memory modules, while dual-fan mode is suited for standard-height RAM. Connect the fan headers to PWM-capable motherboard headers and configure fan curves in BIOS or a fan controller. Use the included Low-Noise Adaptors or motherboard PWM control to limit maximum RPM if desired.

Recommendations

Choose the HBC variant when using Intel LGA1700 CPUs that are used with full ILM pressure or that show concave deformation. For general-purpose builds or AMD AM5 systems, consider the regular or LBC variants for optimal contact quality. Consult the motherboard and RAM compatibility lists to confirm clearance for your specific components and refer to Noctua’s FAQ for details on base convexity and mounting options.
