Acer PD1520Us Ultra Short Throw Projector 500 ANSI Lumens DLP 1080p

The Acer PD1520Us is an ultra-short throw DLP projector that delivers Full HD (1080p) images from very short distances. With a 0.26 throw ratio it can produce up to 100‑inch images while occupying minimal space. The projector uses an LED light source rated up to 20,000 hours and offers 500 ANSI lumens (listed also as 2,000 LED lumens in marketing materials) of brightness, autofocus, built-in 6 W speaker, Wi‑Fi and Bluetooth connectivity, and an optional battery module for up to two hours of cable-free use.

Advantages

Compact and portable, the PD1520Us combines ultra-short throw capability with 1080p resolution to produce large, detailed images from close range. Autofocus reduces setup time by adjusting the image automatically. The LED light source provides long service life, while smart connectivity (Wi‑Fi/Bluetooth) and an integrated speaker simplify media playback and presentations. An optional on‑the‑go battery enables short periods of cordless projection.

Suitable for

• Small meeting rooms and classrooms
• Home cinema in limited spaces
• Tabletop and desktop projection for demos or storytelling
• Portable presentations and on‑site pitching

Key specifications

• Model: Acer PD1520Us (MR.JYE11.001)
• Projection technology: DLP
• Native resolution: 1080p (1920 × 1080), 16:9
• Brightness: 500 ANSI lumens (marketing: 2,000 LED lumens)
• Throw ratio: 0.26 (ultra‑short throw, up to 100" / 2540 mm)
• Screen size compatibility: 762 – 2540 mm (30 – 100")
• Contrast ratio: 10,000:1
• Light source life: LED up to 20,000 hours
• Autofocus: Yes
• Connectivity: Wi‑Fi, Bluetooth
• Speakers: Built‑in 6 W
• Power: AC / optional battery (70 W power consumption)
• Colour: Black
• Weight: 0.7 kg

How to use

Place the projector close to the projection surface and align it so the image fills the intended area; at about 17–20 inches (depending on surface) the unit can project images up to 100 inches. Power on the projector, allow autofocus to adjust the image, and select the input or streaming app via the smart interface. Use Wi‑Fi or Bluetooth to connect mobile devices for media playback, or insert external sources through supported ports. If using the optional battery module, ensure it is charged before cordless use.

Recommendations

For best image quality, project onto a flat, neutral-colour surface and minimize direct ambient light. Use autofocus and the projector’s native 16:9 resolution to avoid scaling artifacts. For presentations in bright rooms, prefer controlled lighting or closer projection distances to maintain contrast.
