ABUS Security-Center VdS Battery 12V 2.0 Ah BT2020

The ABUS Security-Center BT2020 is a high-quality sealed lead-acid (SLA) battery designed for reliable backup power in security and alarm systems. With a nominal voltage of 12V and a capacity of 2.0 Ah, this maintenance-free battery ensures your systems stay operational during power outages. Certified with VDS G109003, it meets stringent safety standards.

Advantages

Maintenance-free operation with leak-proof design ensures safe and hassle-free use. The AGM technology provides low internal resistance and high discharge current capability. With a design life of 3-5 years, it offers long-term reliability for critical applications.

Suitable for

• Security and alarm systems
• Emergency lighting
• UPS systems
• Access control systems

Key specifications

• Battery Type: Sealed Lead-Acid (SLA) / AGM
• Nominal Voltage: 12 V
• Nominal Capacity: 2.0 Ah (C20)
• Design Life: 3-5 years
• Terminal Type: F1 (Faston 4.75mm / 0.187")
• Internal Resistance: Approx. 60 mΩ
• Max. Discharge Current: 30 A (5 sec)
• Max. Charge Current: 0.6 A
• Operating Temperature (Discharge): -15°C to 50°C
• Operating Temperature (Charge): -15°C to 40°C
• Self-Discharge Rate: Approx. 3% per month at 20°C
• Housing Material: ABS
• Certification: VDS G109003

Recommendations

For optimal performance, use with compatible ABUS charging systems. Ensure proper ventilation during charging. Replace every 3-5 years to maintain system reliability.
