Yealink VCM36 Ceiling Microphone Array for Video Conferencing

The Yealink VCM36 is a professional ceiling-mounted microphone array designed to deliver crystal-clear audio for medium to large conference rooms. With 360-degree omnidirectional pickup and a range of up to 6 meters, it ensures every participant is heard. Powered over Ethernet (PoE) and compatible with Yealink MVC, UVC, ZVC series, and RoomPanel, the VCM36 integrates seamlessly into existing setups. Its advanced noise proof technology and echo cancellation provide an immersive conferencing experience.

Advantages

• 360° voice pickup covers the entire room, eliminating dead zones.
• Daisy chain up to 8 units for larger spaces.
• Simple installation with PoE – no separate power supply needed.
• Yealink Noise Proof Technology and echo cancellation ensure clear audio.
• LED indicator for mute/unmute status at a glance.

Suitable for

• Medium to large conference rooms
• Huddle rooms and boardrooms
• Ceiling-mounted installations for unobtrusive design
• Integration with Yealink video conferencing systems

Key specifications

• Microphone Type: Ceiling Microphone
• Pickup Pattern: Omnidirectional (360°)
• Voice Pickup Range: 6 meters (20 feet)
• Frequency Response: 100Hz - 16kHz
• Connectivity: 1 x RJ45 (PoE)
• Daisy Chain Support: Up to 8 units
• Power Supply: Power over Ethernet (PoE)
• Compatibility: Yealink MVC series, UVC series, ZVC series, RoomPanel
• Audio Technology: Yealink Noise Proof Technology, Echo Cancellation
• Installation Type: Ceiling Mount
• LED Indicator: Yes (Mute/Unmute status)
• Color: White
• Number of Microphones: 3 internal microphone arrays
• Signal to Noise Ratio (SNR): 70dB
• Sensitivity: -38dB
• Operating Temperature: 0 to 40°C (32 to 104°F)
• Storage Temperature: -10 to 50°C (14 to 122°F)
• Humidity: 10-90% non-condensing

Recommendations

For optimal audio coverage in large rooms, pair the VCM36 with additional units via daisy chain. Ensure ceiling mounting is secure and within the recommended temperature range. Compatible with all major Yealink video conferencing systems.
