Wire Connector Harting 09 66 512 7601 Black Silver Steel Copper Alloy

The Harting 09 66 512 7601 wire connector is a compact electrical connector combining steel and copper alloy construction with a black and silver finish. Designed for reliable electrical contact, this connector is RoHS-compliant and intended for use in a variety of electrical and electronic assemblies. Each retail pack contains 50 pieces and each connector is lightweight, supporting straightforward handling and installation in dense wiring environments.

Advantages

The connector's steel and copper alloy construction provides a balance of mechanical strength and electrical conductivity. The compact form factor and relatively low weight make the part easy to position in confined spaces. RoHS compliance ensures the materials meet environmental and safety restrictions for lead and other hazardous substances. The black and silver finish aids visual identification and orientation during assembly.

Suitable for

• Wire-to-wire and wire-to-board connections in control cabinets and distribution panels
• Industrial machinery and automation equipment requiring robust electrical contacts
• Prototyping and small-batch production where compact connectors are needed
• Maintenance and repair tasks that require replacement of worn connectors

Key specifications

• Materials: steel and copper alloy construction for combined mechanical strength and conductivity
• Finish: black and silver appearance for visual identification
• Compliance: RoHS-compliant materials
• Weight per piece: approximately 22.78 g
• Pack quantity: 50 pieces per pack

How to use

Prepare the wires by stripping insulation to the appropriate length recommended for the mating connector or terminal. Insert the conductor into the connector contact until secure, making sure the conductor is fully engaged and the connector is oriented correctly. Where applicable, use the suitable crimping or insertion tool recommended for the connector type to ensure a reliable mechanical and electrical connection. After assembly, verify continuity and mechanical retention before finalizing the installation.

Recommendations

Store connectors in a dry, dust-free environment and handle with clean tools to avoid contamination of contact surfaces. Select wire cross-section and insulation strip length compatible with the connector contact design. For critical installations, perform electrical continuity and torque checks where applicable and follow applicable industry standards and local regulations for wiring and safety.
