Wire Connector Crimp Harting 09 11 000 6127 Silver 46g

The Harting Wire Connector Crimp 09 11 000 6127 is a precision-manufactured silver crimp connector designed for reliable electrical terminations. It has a compact form factor with an outer diameter of 1.85 cm and an overall width of 54 mm, and the component weighs 46 g. Silver-plated contacts provide improved conductivity and corrosion resistance, while RoHS compliance confirms the connector meets applicable restrictions on hazardous substances for safe industrial and commercial use.

Advantages

The silver-plated contacts reduce contact resistance and improve long-term electrical performance compared with unplated alternatives. Its compact dimensions and moderate weight make it suitable for confined assemblies and panel installations where space and mass are limited. RoHS compliance and robust crimp termination provide a durable, maintenance-friendly connection that minimizes risk of loosening or intermittent contact under vibration or thermal cycling.

Key specifications

• Outer diameter: 1.85 cm
• Width: 54 mm
• Weight: 46 g
• Contact finish: silver-plated contacts for enhanced conductivity
• Termination type: crimp-style connector for mechanical and electrical coupling
• Compliance: RoHS-compliant materials and manufacturing

How to use

Prepare the conductor by stripping the insulation to the length recommended for the specific crimp barrel, ensuring no stray strands remain. Insert the conductor fully into the crimp barrel and position the connector in an appropriate crimping tool sized for the connector barrel. Apply consistent crimp pressure until the tool’s cycle completes and the conductor is secured. After crimping, inspect the joint for full conductor insertion and absence of loose strands. Install the connector into the mating housing or mounting location according to the system’s wiring diagram, and verify electrical continuity and correct polarity before energizing.

Recommendations

Use a crimping tool matched to the connector barrel and conductor cross-section to ensure a reliable mechanical and electrical joint. Avoid exposing the connector to aggressive chemicals or environments outside the product’s intended operating conditions. For best performance, confirm connector compatibility with mating components and follow applicable safety standards during installation and testing.
