Weidmüller Wire-End Ferrule, Insulated, 4.0 mm², 12 AWG, Blue, 32 A, 100 Pieces

The Weidmüller 1020180000 is a high-quality insulated wire-end ferrule designed for reliable and secure connections in electrical installations. Made from tin-plated electrolytic copper with a polypropylene (PP) insulation sleeve, this ferrule ensures excellent conductivity and durability. Suitable for conductor cross-sections of 4.0 mm² (12 AWG), it is rated for 32 A and operates within a temperature range of -40 °C to +105 °C. Each pack contains 100 pieces, making it ideal for professional and industrial use.

Advantages

Insulated design prevents short circuits and ensures safe handling. Tin-plated copper core provides corrosion resistance and low contact resistance. Complies with DIN 46228 Part 4, UL, CSA, and RoHS standards for quality and safety.

Suitable for

• Control cabinets and switchgear
• Industrial automation and machinery
• Electrical panel wiring
• Terminal block connections

Key specifications

• Product Type: Wire-End Ferrule, Insulated
• Conductor Cross-Section: 4.0 mm² (12 AWG)
• Colour: Blue
• Rated Current: 32 A
• Crimp Length (Metal Tube): 18 mm
• Overall Length: 26 mm
• Material: Electrolytic Copper, tin-plated; Insulation: Polypropylene (PP)
• Temperature Range: -40 °C to +105 °C
• Collar Diameter (D1): 5.8 mm
• Insulation Diameter (D2): 4.8 mm
• Metal Tube Inner Diameter (d1): 3.2 mm
• Metal Tube Outer Diameter (d2): 3.5 mm
• Standards: DIN 46228 Part 4, UL, CSA, RoHS
• Packaging Quantity: 100 pieces

Recommendations

For optimal performance, use with a compatible crimping tool designed for insulated ferrules. Ensure proper wire stripping length before crimping.
