Wall charger EQUIP 1-Port 20W GaN USB-C PD — 100–240V input, 12V max output, white

The Equip 245521 1-Port 20W GaN Slim USB-C PD Charger is a compact USB-C power adapter that uses GaN (Gallium Nitride) technology to provide efficient charging in a slim, portable housing. It supports USB Power Delivery up to 20W and automatically negotiates the optimal output for smartphones, tablets, wireless earbuds, power banks and other USB-C devices, while offering protection against overcurrent, overvoltage and short circuits.

Advantages

GaN technology allows a smaller and cooler charger compared with traditional silicon designs, and the USB-C PD protocol enables fast charging with automatic device detection. The charger’s universal AC input and lightweight, slim design make it convenient for travel and everyday use. Built-in protection circuits minimise risk from electrical faults such as overcurrent, overvoltage, overload and short-circuit.

Key specifications

• Model: Equip 245521
• Power output: Max 20W
• Output profiles: 5V⎓3A / 9V⎓2.22A / 12V⎓1.67A
• USB protocol: USB Power Delivery (PD) 3.0
• Technology: GaN (Gallium Nitride)
• Input voltage: 100–240V AC, 50/60Hz
• Protection: Overcurrent, overvoltage, overload, short-circuit
• Compatibility: Most USB-C smartphones, tablets and USB-C devices
• Design: Slim, lightweight, indoor use
• Color: White

How to use

Insert the charger into an AC outlet within the rated 100–240V range, then connect a USB-C cable between the charger and your device. The PD controller will detect the connected device and supply the appropriate voltage and current up to 20W. During the first charge, monitor the device to confirm compatibility and avoid using damaged cables or ports. Disconnect the charger from the mains when it is not in use.

Recommendations

Use a quality USB-C cable rated for PD charging to ensure full performance. Avoid exposing the charger to moisture, extreme temperatures or direct sunlight. For safe operation, use the charger with devices that support USB-C PD and replace the charger if it shows visible damage.
