Vivolink VLHDMIMAT4X2RS matrix switcher Scaling matrix switcher 7.5 W

Vivolink VLHDMIMAT4X2RS matrix switcher Scaling matrix switcher 7.5 W
Vivolink VLHDMIMAT4X2RS matrix switcher Scaling matrix switcher 7.5 W
Vivolink VLHDMIMAT4X2RS matrix switcher Scaling matrix switcher 7.5 W
Vivolink VLHDMIMAT4X2RS matrix switcher Scaling matrix switcher 7.5 W
Vivolink VLHDMIMAT4X2RS matrix switcher Scaling matrix switcher 7.5 W
Vivolink VLHDMIMAT4X2RS matrix switcher Scaling matrix switcher 7.5 W
Vivolink VLHDMIMAT4X2RS matrix switcher Scaling matrix switcher 7.5 W
Vivolink VLHDMIMAT4X2RS matrix switcher Scaling matrix switcher 7.5 W
Vivolink VLHDMIMAT4X2RS matrix switcher Scaling matrix switcher 7.5 W
Vivolink VLHDMIMAT4X2RS matrix switcher Scaling matrix switcher 7.5 W
Vivolink VLHDMIMAT4X2RS matrix switcher Scaling matrix switcher 7.5 W
Vivolink VLHDMIMAT4X2RS matrix switcher Scaling matrix switcher 7.5 W
R7,994
VLHDMIMAT4X2RS is a 4K HDR capable 4x2 HDMI Matrix Switcher that features 18Gbps bandwidth and HDCP2.2 on all inputs and outputs. It’s fully compliant with HDMI2.0 standard and backward compatible with old HDMI1.4 sources and displays. SPDIF and 3.5mm audio breakout audio from corresponding HDMI out... Read More
Stock 4 Code 1189368 Brand VIVOLINK Model VLHDMIMAT4X2RS Warranty 2 Years

Shipping & Returns

Estimated delivery Tuesday, October 6
You will be kept updated through our detailed tracking system
Payment options
EFTPayFastBank CardSnapScanZapperGoogle PayApple PayMobicredMoreTymePay on Arrival
VLHDMIMAT4X2RS is a 4K HDR capable 4x2 HDMI Matrix Switcher that features 18Gbps bandwidth and HDCP2.2 on all inputs and outputs. It’s fully compliant with HDMI2.0 standard and backward compatible with old HDMI1.4 sources and displays. SPDIF and 3.5mm audio breakout audio from corresponding HDMI outputs.


Smart EDID management.
True 4K matrix switcher that can be controlled via WEB GUI (not telnet)

Vivolink VLHDMIMAT4X2RS. Product type: Scaling matrix switcher, Maximum resolution: 3840 x 2160 pixels, Bandwidth: 18 Gbit/s. Housing colour: Black, Control type: Buttons. HDMI version: 2.0b, USB connector type: Micro-USB. Power consumption (max): 7.5 W, AC input voltage: 100 - 240 V, AC input frequency: 50 - 60 Hz. Width: 200 mm, Depth: 100 mm, Height: 28.5 mm

Key Highlights
  • 4x2 HDMI presentation switcher with matrix outputs
  • HDMI 2.0b, 4K@60Hz 4:4:4 8bit, HDR 10, HDCP 2.2
  • RS232, IR and WEB GUI control (not telnet)
  • 4K to 1080p down-scaling
  • SPDIF and 3.5mm output for dual HDMI OUT audio extraction and dual HDMI OUT ARC
  • Smart EDID management
  • True 4K matrix switcher that can be controlled via WEB GUI
  • Scaling matrix switcher Black
  • Maximum resolution: 3840 x 2160 pixels
  • HDCP
  • HDMI input ports quantity: 4 HDMI output ports quantity: 2 RJ-45 input ports: 1
  • 7.5 W
Specifications
AC adapter included
Yes
AC input frequency
50 - 60 Hz
AC input voltage
100 - 240 V
Audio (L/R) out
1
Audio formats supported
PCM
Bandwidth
18 Gbit/s
Built-in display
No
Cables included
IR sensor
Control type
Buttons
Depth
100 mm
Digital audio optical out
1
Ethernet LAN (RJ-45) ports
1
Extended display identification data (EDID)
Yes
Harmonized System (HS) code
85299097
HDCP
Yes
HDCP version
2.2
HDMI input ports quantity
4
HDMI output ports quantity
2
HDMI version
2.0b
Height
28.5 mm
High Dynamic Range (HDR) supported
Yes
Housing colour
Black
LED indicators
Yes
Maximum resolution
3840 x 2160 pixels
Mounting brackets included
No
Operating temperature (T-T)
-5 - 55 °C
Output current
1000 mA
Output voltage
12 V
Package depth
233 mm
Package height
84 mm
Package weight
1.05 kg
Package width
264 mm
Power consumption (max)
7.5 W
Product type
Scaling matrix switcher
Remote control included
Yes
RJ-45 input ports
1
RS-232 ports
1
USB connector type
Micro-USB
USB ports quantity
1
Weight
860 g
Width
200 mm

Manual

Open Manual

Leaflet

Open Leaflet
