Video/Audio BNC Adapter ShiverPeaks 98809-1 — BNC connections for video and audio signals

ShiverPeaks 98809-1 is a compact Video/Audio BNC adapter that provides a reliable BNC coupling for video and audio signal transmission over coaxial cabling. Designed as a simple interface between devices with BNC connectors, this adapter supports connections between cameras, monitors, recorders and audio equipment in installations and service environments where a compact, passive BNC join is required.

Advantages

The adapter offers a space-saving, passive solution for joining or extending BNC connections without tools or additional hardware. Its standardized BNC interfaces ensure mechanical compatibility with common coaxial cables and devices, while the robust construction supports repeated mating cycles and in-field handling. The product facilitates quick, temporary or permanent connections during setup, testing and maintenance tasks.

Suitable for

• Connecting CCTV cameras to monitors or DVRs during installation and testing
• Linking audio equipment that uses BNC coaxial connectors in broadcast or studio environments
• Extending or joining coaxial runs when performing maintenance or troubleshooting
• Temporary signal routing in field service and system commissioning

Key specifications

• Connector type: BNC female to BNC female passive adapter
• Impedance: compatible with 50 Ω coaxial systems for video and audio applications
• Suitable cable types: standard RG58 and similar 50 Ω coaxial cables
• Form factor: compact inline coupler for easy installation in tight spaces
• Mechanical durability: designed for repeated connections and field use

How to use

Align the BNC plug of the coaxial cable with the adapter's BNC socket, push in and twist to lock the bayonet connection. Repeat the procedure for the second cable or device on the opposite side. Ensure connectors are fully seated and locked to maintain a stable electrical contact. For best results, use clean, undamaged BNC plugs and properly terminated coaxial cables rated for 50 Ω operation.

Recommendations

Use this adapter for temporary joins and diagnostic connections rather than as a permanent cabling solution in critical signal paths. Inspect connectors for corrosion or damage before use, and avoid excessive bending of coaxial cable near the adapter to maintain impedance integrity.
