Uni-T UTi720M Thermal Imaging Camera 256x192, -20°C to 550°C, 3.5 inch IPS LCD, IP54

The Uni-T UTi720M is a professional handheld thermal imaging camera designed for electrical inspections, building diagnostics, and preventive maintenance. With a 256x192 thermal resolution and a wide temperature range of -20°C to 550°C, it delivers accurate temperature measurements for a variety of applications. The 3.5-inch IPS LCD display provides clear image viewing, while the IP54 rating and 2-meter drop resistance ensure durability in demanding environments.

Advantages

High thermal sensitivity (<50mK) for detecting subtle temperature differences. Fusion mode with picture-in-picture allows overlay of thermal and visible images for easy problem identification. Long battery life of up to 6 hours supports extended fieldwork. Expandable storage via SD card up to 32GB ensures ample space for image capture.

Suitable for

• Electrical fault detection and troubleshooting
• Building insulation and moisture inspection
• Mechanical and industrial equipment monitoring
• HVAC system diagnostics

Key specifications

• Thermal Resolution: 256 x 192 pixels
• Temperature Range: -20°C to 550°C
• Accuracy: ±2°C or ±2%
• NETD: <50mK
• Frame Rate: 25 Hz
• Field of View: 56° x 42°
• Display: 3.5-inch IPS LCD, 640x480
• Focus: Fixed
• Emissivity: Adjustable 0.01-0.99
• Storage: 16GB SD card (expandable to 32GB)
• Connectivity: USB Type-C
• Battery Life: Up to 6 hours
• IP Rating: IP54
• Drop Resistance: 2 meters
• Visible Camera: 5 MP
• Image Modes: Thermal, Fusion, Visible
• Spectral Response: 8-14 μm
• Temperature Alarm: High/Low

Recommendations

For professionals requiring reliable thermal imaging with high accuracy and durability, the Uni-T UTi720M is an excellent choice. Its combination of advanced features and robust build makes it suitable for daily use in challenging environments.
