UNI-T UT53 Digital Multimeter with Insulation Tester

The UNI-T UT53 is a professional digital multimeter and insulation tester that delivers precise measurements up to 1000V DC and 1000V AC True RMS. Its standout capability is insulation resistance testing up to 10GΩ with selectable test voltages from 50V to 1000V, making it ideal for diagnosing motor windings, cables, and electrical installations.

Advantages

This instrument combines a 6000-count multimeter with a full-featured insulation tester. Auto-ranging simplifies operation, while True RMS ensures accurate readings on non-sinusoidal waveforms. The large backlit display and data hold function improve usability in dim environments. Safety is paramount: CAT III 1000V and CAT IV 600V ratings allow confident use in industrial and utility settings.

Suitable for

• Electrical maintenance and troubleshooting in industrial plants
• Insulation testing of motors, transformers, and cables
• Verification of electrical installations per IEC/EN standards
• Field service for HVAC, solar, and power distribution
• Education and advanced electronics labs

Key specifications

• Display: 6000 counts, backlit
• DC voltage: 600mV to 1000V
• AC voltage (True RMS): 6V to 1000V
• DC/AC current: 60mA to 600mA
• Resistance: 600Ω to 60MΩ
• Capacitance: 10nF to 100μF
• Frequency: 60Hz to 60MHz
• Insulation test voltages: 50V, 100V, 250V, 500V, 1000V
• Insulation resistance: 0.1MΩ to 10GΩ
• PI and DAR tests for insulation quality
• Continuity buzzer and diode test
• Auto range, data hold, backlight
• Safety: CAT III 1000V, CAT IV 600V
• Power: 6 x 1.5V AA batteries

Recommendations

For technicians who need both general-purpose multimeter functions and high-voltage insulation testing, the UNI-T UT53 is a reliable, all-in-one solution. Its rugged design and comprehensive safety ratings make it a smart investment for demanding electrical work.
