Ubiquiti UCG-Industrial Gateway and Controller 1/2.5/10 Gbps

The Ubiquiti UCG-Industrial is a compact, high-performance gateway and controller designed for industrial environments. It integrates the UniFi Network Application, providing powerful routing, firewall, and VPN capabilities in a rugged form factor. With dual-core ARM Cortex-A53 processor and 3 GB DDR4 RAM, it delivers reliable throughput up to 1 Gbps, making it ideal for demanding industrial networks.

Advantages

All-in-one gateway and controller eliminates the need for separate hardware. Industrial-grade design ensures stable operation in harsh conditions. Easy setup and management via UniFi Network Application (web or mobile).

Suitable for

• Industrial automation and control networks
• Remote site connectivity with VPN
• Small to medium business deployments requiring integrated controller

Key specifications

• Processor: Dual-core ARM Cortex-A53 @ 1.7 GHz
• System Memory: 3 GB DDR4
• On-Board Storage: 16 GB eMMC
• WAN Port: 1x 1 GbE RJ45
• LAN Ports: 4x 1 GbE RJ45
• Max. Routing Throughput: 1 Gbps
• Power Method: USB-C (5V DC, 3A)
• Power Supply: 5V DC, 3A adapter included
• Max. Power Consumption: 3.8W
• Operating Temperature: -10 to 40°C
• Mounting: Desktop (wall-mountable optional)

Recommendations

For optimal performance, use with Ubiquiti UniFi switches and access points. The UCG-Industrial is an excellent choice for industrial IoT gateways and SD-WAN deployments.
