R8,202
TP-Link Omada DS105X, Unmanaged, 10G Ethernet (100/1000/10000), Wall mountable TP-Link Omada DS105X. Switch type: Unmanaged. Basic switching RJ-45 Ethernet ports type: 10G Ethernet (100/1000/10000), Basic switching RJ-45 Ethernet ports quantity: 5. MAC address table: 16000 entries, Switching capaci... Read More
Stock Out Of StockNo Stock Code 2402130 Brand TP-LINK Model DS105X Warranty 2 Years

Shipping & Returns

TP-Link Omada DS105X, Unmanaged, 10G Ethernet (100/1000/10000), Wall mountable

TP-Link Omada DS105X. Switch type: Unmanaged. Basic switching RJ-45 Ethernet ports type: 10G Ethernet (100/1000/10000), Basic switching RJ-45 Ethernet ports quantity: 5. MAC address table: 16000 entries, Switching capacity: 100 Gbit/s. Networking standards: IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3an, IEEE 802.3bz, IEEE 802.3u, IEEE 802.3x. DC input voltage: 12 V. Power connector: DC-in jack. Wall mountable

Key Highlights
  • Five 10 Gbps Ports. 5× 10-Gigabit ports unlock the highest performance of your 10G/Multi-Gig bandwidth and devices, and provide up to 100 Gbps of switching capacity
  • Lightning-Fast Connections. Provides lightning-fast connections to 10G NAS, Server, 10G PCIe Adapter/ NIC, gaming computer, 2.5G/5G/10G WiFi 6 AP, 8K video, and more
  • Ideal for Various Scenarios. Built for lightning-fast connections in LAN parties, home entertainment, small and home offices, and workstations
  • Optimal 5-Speed Connections. Auto-negotiation for 5-speed (100Mbps/1G/2.5G/5G/10G) connections provide optimal performance
  • Silent Operation. The revolutionary fanless design ensures unprecedented silent operation, ideal for any home or business
  • Durable Metal Casing. Durable metal casing, desktop/wall-mounting, and professional heat dissipation design are well suited for different environments
  • Plug and Play. No configuration or central management required
  • Unmanaged
  • Quality of Service (QoS) support
  • Basic switching RJ-45 Ethernet ports quantity: 5
  • 10G support 10GBASE-T, 100BASE-TX, 1000BASE-T
  • MAC address table: 16000 entries Switching capacity: 100 Gbit/s
  • AC Power supply included
Specifications
10G support
Yes
AC input frequency
50/60 Hz
AC input voltage
100 - 240 V
Auto MDI/MDI-X
Yes
Auto-negotiation
Yes
Basic switching RJ-45 Ethernet ports quantity
5
Basic switching RJ-45 Ethernet ports type
10G Ethernet (100/1000/10000)
Cables included
Power
Compliance certificates
CE, EAC, Federal Communications Commission (FCC), Industry Canada (IC), RoHS, UKCA
Copper ethernet cabling technology
10GBASE-T, 100BASE-TX, 1000BASE-T
DC input voltage
12 V
Depth
131.2 mm
Ethernet LAN data rates
10,100,1000,2500,5000,10000 Mbit/s
Fanless
Yes
Flow control support
Yes
Forwarding rate
74.4 Mpps
Heat dissipation
85.65 BTU/h
Height
35 mm
Housing material
Metal
IGMP snooping
Yes
Input current
2 A
Jumbo frames
12
Jumbo frames support
Yes
LED indicators
Activity, Link, Power
MAC address table
16000 entries
Multicast support
Yes
Networking standards
IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3an, IEEE 802.3bz, IEEE 802.3u, IEEE 802.3x
Operating relative humidity (H-H)
10 - 90%
Operating temperature (T-T)
0 - 40 °C
Packet buffer memory
12 MB
Plug and Play
Yes
Power connector
DC-in jack
Power consumption (max)
25.19 W
Power over Ethernet (PoE)
No
Power source
AC
Power supply included
Yes
Product colour
Black
Quality of Service (QoS) support
Yes
Reset button
Yes
Rubber feet
Yes
Storage relative humidity (H-H)
5 - 90%
Storage temperature (T-T)
-40 - 70 °C
Store-and-forward
Yes
Switch type
Unmanaged
Switching capacity
100 Gbit/s
User guide
Yes
Wall mountable
Yes
Width
226 mm

Leaflet

Open Leaflet

Manual

Open Manual
