TP-Link INSIGHT S445 Turret IP security camera Outdoor 2688 x 1520 pixels Ceiling

The TP-Link INSIGHT S445 is an outdoor IP security camera with a 2688 x 1520 pixels resolution and turret form factor, designed for wired ceiling mounting. It uses a CMOS sensor to deliver clear, detailed footage and offers a wide field of view (80.4° horizontal, 41.8° vertical, 98.7° diagonal). The camera supports people and vehicle analytics and classification to speed up post-event search and provide more accurate event notifications.

Advantages

True WDR balances bright and dark areas for natural-looking images in high-contrast lighting. Smart IR adjusts infrared illumination to reduce overexposure and glare, improving night visibility. 3D DNR reduces noise across frames while preserving detail, and White Balance maintains neutral whites under varying light. Efficient H.265+ compression reduces bandwidth and storage needs while keeping image quality, saving up to 57.5% vs H.264 and 15% vs H.265.

Suitable for

• Outdoor perimeter and entrance monitoring
• Parking lots and vehicle access points
• Commercial and public building ceiling surveillance
• Sites requiring people and vehicle analytics for post-event search

Key specifications

• Resolution: 2688 x 1520 pixels
• Form factor: Turret (outdoor)
• Lens / MPN: InSight S445(4mm)
• Connectivity: Wired Ethernet (no Wi‑Fi)
• Field of view: 80.4° horizontal / 41.8° vertical / 98.7° diagonal
• Sensor: CMOS
• S/N ratio: 52 dB
• Placement: Outdoor, ceiling mount supported
• Colour: White
• Video analytics: People & Vehicle Analytics, Human & Vehicle Classification
• Compression: H.265+
• Weight: 0.48 kg

How to use

Mount the camera on a suitable outdoor ceiling or eave using appropriate fixings and wiring for a wired Ethernet connection. Configure network settings and enable analytics features in the TP-Link management interface or compatible NVR/management software. Adjust orientation to cover the desired area within the 80.4° horizontal field of view and set IR and image parameters (WDR, White Balance, 3D DNR) as needed for the scene.

Recommendations

For reliable analytics and image quality, install the camera at a height and angle that provide clear views of faces and vehicle plates where required, avoid direct exposure to strong light sources within the frame, and use stable wired network infrastructure and sufficient storage configured for H.265+ streams.
