TMSS Germany Inductive Proximity Sensor XS8C4A1MPG13, 24-240V AC/DC, M30, 20mm Sensing, NO, IP67/IP69K

Inductive proximity sensor with a 20 mm sensing distance, cylindrical M30 plastic housing, and 2-wire AC/DC operation. Rated for 24-240 V AC/DC and built to withstand harsh environments with IP67 and IP69K protection.

Advantages

Non-flush mountable design allows flexible installation. Wide supply voltage range (24-240 V AC/DC) simplifies integration into existing control systems. Durable PBT plastic housing resists corrosion and mechanical stress.

Suitable for

• Position sensing on industrial machinery
• Object detection in automated production lines
• Harsh environments requiring high ingress protection

Key specifications

• Sensor type: Inductive proximity sensor
• Series: OsiSense XS
• Model designation: XS8
• Sensor design: Cylindrical M30
• Sensing distance: 20 mm
• Mounting: Non-flush
• Output type: Discrete, 1 NO (normally open)
• Wiring technique: 2-wire
• Rated supply voltage: 24-240 V AC/DC
• Switching frequency: ≤ 500 Hz
• Maximum switching current: 200 mA
• Electrical connection: Cable gland 1/2" NPT
• Housing material: Plastic (PBT)
• IP rating: IP67, IP69K
• Operating temperature: -25 to 70 °C
• Thread type: M30 x 1.5
• Length: 74 mm

Recommendations

For reliable detection of metallic objects in demanding industrial environments, pair this sensor with a compatible PLC input module rated for 24-240 V AC/DC.
