TIVENTO FLEX Copper Pipe with Insulation 1/2 inch 50 m Coil

The TIVENTO FLEX Copper Pipe with Insulation is a high-quality, pre-insulated copper tube designed for refrigeration, air conditioning, heating, and plumbing applications. This 50-meter coil features a soft annealed copper pipe (Cu-DHP) with an outer diameter of 12.7 mm (1/2 inch) and a wall thickness of 0.8 mm, meeting EN 12735-1 standards. The pipe is covered with a 9 mm thick closed-cell polyethylene (PE) foam insulation, providing excellent thermal efficiency and condensation control. The insulation is black, UV-resistant, and moisture-resistant, with a thermal conductivity of ≤ 0.040 W/(m·K) at 0°C and an operating temperature range of -40°C to +120°C. This flexible coil is easy to install and ideal for long runs in HVAC systems.

Advantages

Pre-insulated copper pipe saves installation time and ensures consistent thermal performance. The closed-cell foam insulation prevents heat loss and reduces condensation, improving system efficiency. The soft annealed copper is flexible yet durable, allowing for easy bending without kinking. UV and moisture resistance make it suitable for both indoor and outdoor use.

Suitable for

• Refrigeration and air conditioning systems
• Heating and plumbing installations
• Split system connections
• Chilled water lines

Key specifications

• Pipe Material: Copper (Cu-DHP) per EN 12735-1
• Nominal Diameter: 1/2 inch (OD 12.7 mm)
• Wall Thickness: 0.8 mm
• Length: 50 meters
• Insulation: Closed-cell PE foam, 9 mm thick
• Thermal Conductivity: ≤ 0.040 W/(m·K) at 0°C
• Operating Temperature: -40°C to +120°C
• Fire Class: Euroclass E (EN 13501-1)
• Colour: Black
• Packaging: Coil

Recommendations

For optimal performance, ensure proper support and avoid sharp bends. Use appropriate fittings and tools for copper pipe installation. Store in a dry, clean area to maintain insulation integrity.
