TELTONIKA Trb246 4g/lte Gateway

TELTONIKA Trb246 4g/lte Gateway
TELTONIKA Trb246 4g/lte Gateway
TELTONIKA Trb246 4g/lte Gateway
TELTONIKA Trb246 4g/lte Gateway
TELTONIKA Trb246 4g/lte Gateway
TELTONIKA Trb246 4g/lte Gateway
TELTONIKA Trb246 4g/lte Gateway
TELTONIKA Trb246 4g/lte Gateway
TELTONIKA Trb246 4g/lte Gateway
TELTONIKA Trb246 4g/lte Gateway
TELTONIKA Trb246 4g/lte Gateway
TELTONIKA Trb246 4g/lte Gateway
TELTONIKA Trb246 4g/lte Gateway
TELTONIKA Trb246 4g/lte Gateway
TELTONIKA Trb246 4g/lte Gateway
TELTONIKA Trb246 4g/lte Gateway
TELTONIKA Trb246 4g/lte Gateway
TELTONIKA Trb246 4g/lte Gateway
R2,919
The TRB246 is an industrial 4G LTE gateway equipped with I/Os, RS232, RS485, and Ethernet interfaces for IoT solutions requiring versatility and reliable M2M communication support. This gateway has dual SIM functionality and supports multiple protocols, like DNP3, DLMS, and Modbus, vital for ensurin... Read More
Stock 1 Code 91484 Brand TELTONIKA Model TRB246000600 Warranty 2 Years

Shipping & Returns

Estimated delivery Tuesday, October 6
You will be kept updated through our detailed tracking system
Payment options
EFTPayFastBank CardSnapScanZapperGoogle PayApple PayMobicredMoreTymePay on Arrival

The TRB246 is an industrial 4G LTE gateway equipped with I/Os, RS232, RS485, and Ethernet interfaces for IoT solutions requiring versatility and reliable M2M communication support. This gateway has dual SIM functionality and supports multiple protocols, like DNP3, DLMS, and Modbus, vital for ensuring smooth data transmission. Encased in aluminium housing, this industrial-grade IoT gateway can tolerate extreme environmental conditions in manufacturing, agriculture, or construction.

Key Highlights
  • CONNECTIVITY
  • 4G/LTE (Cat 4), 3G, 2G
  • DUAL SIM
  • Auto-failover, backup WAN, and more switching scenarios
  • INTERFACES
  • Ethernet, I/Os, and serial (RS232, RS485) interfaces with 16-pin terminal block
  • PROTOCOLS
  • Supports DNP3, DLMS, Modbus, and other communication protocols
Specifications
Antenna connector type
SMA
Antenna type
External
Antennas quantity
2
Auto MDI/MDI-X
Yes
BeiDou
Yes
Built-in processor
Yes
Certification
CE, UKCA, RCM, CB, EAC, UCRF, WEEE
Data network
2G, 3G, 4G, LTE
Data transfer rate (LTE) (download)
150 Mbit/s
Data transfer rate (LTE) (upload)
50 Mbit/s
Depth
74.2 mm
Device type
Cellular network gateway
DHCP server
Yes
DMZ support
Yes
Embedded GNSS
Yes
Ethernet LAN
Yes
Ethernet LAN (RJ-45) ports
1
Ethernet LAN data rates
10,100 Mbit/s
Ethernet LAN interface type
Fast Ethernet
External power adapter
Yes
Full duplex
Yes
Galileo
Yes
GLONASS
Yes
GPS (satellite)
Yes
Height
25 mm
Housing material
Aluminium
Input voltage
9 - 30 V
Internal storage capacity
0.016 GB
LED indicators
LAN, Power, Signal strength, Status
Management platform
RMS
Market positioning
Industrial
Mounting
DIN-rail/Wall mounting
Networking standards
IEEE 802.11e, IEEE 802.3, IEEE 802.3az, IEEE 802.3u
Number of SIM cards
2
Operating relative humidity (H-H)
10 - 90%
Operating temperature (T-T)
-40 - 75 °C
Port forwarding
Yes
Power source type
DC
Processor frequency
0.58 GHz
Processor manufacturer
Mediatek
Product colour
Black
Quasi-Zenith Satellite System (QZSS)
Yes
RAM capacity
0.128 GB
RAM type
DDR2
RS-232 signals
CTS, RTS, Rx, Tx
RS-485 signals
Data+, Data-, RDA-, RDB+
Serial interface type
RS-232, RS-232/485
Serial ports quantity
1
Short Message Service (SMS)
Yes
SIM card type
MiniSIM
SIM interface
3 V
Suitable for indoor use
Yes
Web-based management
Yes
Weight
165 g
Wi-Fi
No
Width
83 mm
