Telegärtner J08071A0052 LC Multimode OM3/OM4 Simplex Connector, Violet

The Telegärtner J08071A0052 stands apart from generic LC connectors through its precision zirconia ferrule and crimp termination, engineered for reliable multimode connections in demanding environments. This simplex connector is colour-coded violet for OM3/OM4 identification, ensuring quick recognition in high-density fibre installations. With a typical insertion loss of just 0.1 dB and a maximum of 0.25 dB, it delivers consistent optical performance for Gigabit and 10 Gigabit Ethernet links. The connector supports 3.0 mm cable diameters, making it suitable for both patch cords and pigtails in enterprise and data centre networks.

Highlights

• LC simplex connector for multimode fibre (OM3/OM4)
• Zirconia ceramic ferrule for durability and precise alignment
• Low insertion loss: typical 0.1 dB, max 0.25 dB
• Violet housing for easy identification of OM3/OM4
• Crimp termination for secure cable retention
• Supports 3.0 mm cable diameter
• Operating temperature range: -40°C to +85°C
• Compliant with IEC 61753-1 Category U

In daily use

Field technicians appreciate the J08071A0052 for its straightforward crimp termination, which reduces installation time without sacrificing reliability. The violet colour coding eliminates guesswork when patching OM3 or OM4 links, preventing costly mismatches. The connector's robust plastic housing and ceramic ferrule withstand frequent mating cycles—over 1000—making it ideal for patch panels, wall outlets, and active equipment. Whether building a new fibre backbone or repairing an existing link, this connector provides consistent low-loss performance.

Full specifications

• Brand: Telegärtner
• Model: J08071A0052
• MPN: 100007167
• EAN: 4018359468460
• Connector type: LC
• Fibre mode: Multimode
• Fibre category: OM3 / OM4
• Polishing type: PC (Physical Contact)
• Number of fibres: Simplex (1 fibre)
• Ferrule material: Zirconia ceramic
• Housing material: Plastic
• Insertion loss (typical): 0.1 dB
• Insertion loss (max): 0.25 dB
• Return loss (min): 20 dB
• Return loss (typical): 30 dB
• Mating cycles: > 1000
• Operating temperature: -40°C to +85°C
• Storage temperature: -40°C to +85°C
• Cable compatibility: 3.0 mm cable diameter
• Termination type: Crimp
• Standard compliance: IEC 61753-1 Cat. U
• Colour: Violet
• Pack size: 1 piece

Final note

For installers and network managers who demand precision and longevity, the Telegärtner J08071A0052 is a proven choice. Its violet OM3/OM4 coding and low-loss performance keep your multimode links running at full speed, while the rugged construction ensures years of dependable service.
