TECHLY OM4 Multimode Fiber Optic Patch Cable LC-LC Duplex 3m Aqua

The TECHLY OM4 Multimode Fiber Optic Patch Cable is a high-performance duplex patch cord designed for reliable data transmission in demanding network environments. With LC to LC connectors and a length of 3 meters, this cable supports high-speed applications up to 100GbE, making it ideal for data centers, enterprise networks, and telecommunications.

Advantages

Optimized for OM4 multimode fiber, this patch cable delivers low insertion loss and high return loss, ensuring signal integrity over longer distances. The LSZH (Low Smoke Zero Halogen) jacket provides enhanced safety in confined spaces, while the aqua color allows for easy identification. Durable zirconia ceramic ferrules guarantee consistent performance and longevity.

Suitable for

• 10GbE, 40GbE, and 100GbE networks (IEEE 802.3ae, 802.3ba)
• Data center interconnects
• Storage area networks (SAN)
• High-speed computing clusters
• Telecommunications infrastructure

Key specifications

• Fiber Type: OM4 Multimode (50/125 µm)
• Connectors: LC to LC, Duplex
• Length: 3 meters
• Jacket: LSZH, Aqua
• Insertion Loss: ≤ 0.3 dB
• Return Loss: ≥ 30 dB
• Operating Temperature: -20°C to +70°C
• Compliance: RoHS, CE

Recommendations

For optimal performance, ensure connectors are clean before installation. This cable is compatible with all standard LC interfaces and supports wavelengths of 850 nm and 1300 nm.
