SYNERGY21 LED Light Panel R400 with Power Supply Unit Triac Dimm

The SYNERGY21 LED Light Panel R400 is a high-quality, energy-efficient lighting solution designed for professional and residential use. With a round shape and a diameter of 400 mm, this panel delivers a luminous flux of 2400 lumens at a power consumption of only 24 W, making it an excellent choice for ambient lighting. The warm white color temperature of 3000 K creates a cozy atmosphere, while the Triac dimmable feature allows for flexible brightness control. The panel includes an external LED driver (power supply unit) and is suitable for recessed mounting. Its aluminum frame and PMMA diffuser ensure durability and even light distribution. Ideal for offices, living rooms, and commercial spaces, this panel offers a long lifespan of 50,000 hours and an energy efficiency class of A+.

Advantages

Energy-efficient LED technology with 24 W power consumption and 2400 lm output. Triac dimmable for customizable lighting. Long lifespan of 50,000 hours reduces maintenance costs. Easy installation with included driver. High color rendering index (CRI >80 Ra) for true color representation.

Suitable for

• Office lighting
• Living rooms and bedrooms
• Commercial spaces such as shops and showrooms
• Hotels and restaurants
• Recessed ceiling installations

Key specifications

• Light Source: LED
• Power Consumption: 24 W
• Luminous Flux: 2400 lm
• Color Temperature: 3000 K (Warm White)
• Dimming: Triac Dimmable (Phase Cut)
• Shape: Round
• Diameter: 400 mm
• Panel Thickness: 10.5 mm
• Input Voltage: 220-240 V AC
• Output Voltage (Driver): 24 V DC
• Beam Angle: 120°
• CRI: >80 Ra
• Protection Class: IP20
• Material: Aluminum (frame), PMMA (diffuser)
• Mounting: Recessed
• Included: LED Panel, LED Driver
• Energy Efficiency Class: A+
• Operating Temperature: -20°C to +45°C

Recommendations

For optimal performance, ensure proper ventilation around the driver. Compatible with standard Triac dimmers. Surface mount kit available separately for surface mounting.
