Supermicro MCP-350-30206-0N Fan Cooling Module

The Supermicro MCP-350-30206-0N Fan Cooling Module is a high-performance, hot-swappable cooling solution designed for Supermicro server chassis. Featuring a 40x40x28mm dual ball bearing fan with PWM control, it delivers reliable airflow and efficient heat dissipation for demanding server environments.

Advantages

Hot-swappable design allows for easy replacement without system downtime. Dual ball bearing construction ensures long operational life and stable performance under continuous use. The 4-pin PWM connector enables precise fan speed control, balancing cooling performance and noise levels.

Suitable for

• Supermicro 1U/2U/3U/4U server chassis requiring enhanced cooling
• Data centers and enterprise server rooms
• High-performance computing applications

Key specifications

• Product Type: Fan Cooling Module
• Fan Size: 40 x 40 x 28 mm
• Internal Fan Model: FAN-0100L4
• Connector: 4-pin PWM
• Rated Voltage: 12V DC
• Rated Current: 0.45 A
• Power Consumption: 5.4 W
• Max Fan Speed: 12800 RPM
• Max Airflow: 20.5 CFM
• Max Noise Level: 50 dBA
• Bearing Type: Dual Ball Bearing
• Hot-Plug Support: Yes
• Material: Plastic (fan), Metal (bracket)

Recommendations

Ensure compatibility with your Supermicro chassis model before purchase. This module is designed for internal server cooling and should be installed by qualified personnel.
