Sky-Watcher Wave 150i Hybrid Harmonic Mount

The Sky-Watcher Wave 150i Hybrid Harmonic Mount is a cutting-edge equatorial mount designed for astrophotographers and visual observers who demand precision, portability, and ease of use. Featuring a hybrid harmonic drive system on both RA and DEC axes, this mount delivers smooth, accurate tracking without the need for counterweights in many setups. With a payload capacity of up to 20 kg (with counterweight), it supports a wide range of telescopes and imaging equipment. The integrated SynScan Go-To system with Wi-Fi control allows for effortless alignment and target acquisition via smartphone or tablet. Built from CNC-machined aluminum alloy, the Wave 150i is both lightweight and durable, making it an ideal companion for remote observing sessions or travel.

Advantages

The hybrid harmonic drive eliminates the need for heavy counterweights in many configurations, reducing setup time and overall weight. The dual Vixen/Losmandy saddle accommodates most telescope brands, and the built-in Wi-Fi enables wireless control via the SynScan app. With permanent periodic error correction (PEC) and high-resolution encoders, the mount achieves exceptional tracking accuracy for long-exposure astrophotography.

Suitable for

• Astrophotographers requiring a portable, high-precision mount for deep-sky imaging
• Visual observers who want quick setup and reliable tracking
• Users with telescopes up to 20 kg (with counterweight) or 15 kg (without counterweight)
• Remote or field use where weight and power consumption are critical

Key specifications

• Mount Type: Hybrid Harmonic Drive Equatorial
• Drive System: Harmonic Drive (RA & DEC)
• Imaging Payload Capacity (without CW): 15 kg (33 lbs)
• Imaging Payload Capacity (with CW): 20 kg (44 lbs)
• Mount Head Weight: 3.8 kg (8.4 lbs)
• Latitude Adjustment Range: 0° to 90°
• Azimuth Adjustment Range: ± 5°
• Power Requirement: DC 12V, 3A
• Power Consumption (Tracking): 0.35A
• Power Consumption (Go-To Max): 1.5A
• Autoguiding Port: ST-4 compatible
• Communication Interfaces: USB-C, Wi-Fi, Hand Controller Port
• Go-To Speeds: Up to 1000x sidereal
• Tracking Modes: Sidereal, Solar, Lunar
• Dovetail Saddle Type: Dual Vixen/Losmandy (D/V)
• Materials: CNC Machined Aluminum Alloy
• Permanent Periodic Error Correction (PEC): Yes
• Encoder Resolution: 0.17 arc-seconds
• Control System: SynScan Go-To (Wi-Fi enabled)
• Operating Temperature: -20°C to 50°C

Recommendations

For optimal performance, pair the Wave 150i with a compatible Sky-Watcher telescope and a 12V power supply. Use the SynScan app for easy alignment and control. For astrophotography, consider adding an autoguider via the ST-4 port to enhance tracking accuracy.
