SilverStone SST-XE02-TR5B Low Profile CPU Cooler, 60mm Fan, Black Aluminum, Copper Base, Intel LGA1150/1151/1155/1156, PWM, 65W TDP

The SilverStone SST-XE02-TR5B is a low profile CPU cooler designed for space-constrained systems such as Intel NUC, Mini-ITX, and small form factor PCs. Featuring a 60mm PWM fan with speeds from 1200 to 3500 RPM, it delivers efficient cooling for CPUs with TDP up to 65W. The heatsink combines aluminum fins with a copper base for optimal heat transfer, while the pre-applied thermal paste simplifies installation.

Advantages

Compact design fits tight enclosures; PWM control allows quiet operation at low loads; copper base enhances thermal conductivity; push-pin mounting for easy installation.

Suitable for

• Intel NUC systems
• Mini-ITX motherboards
• Small form factor PCs
• Low-profile builds requiring efficient cooling

Key specifications

• Cooler Type: Low Profile CPU Cooler
• Socket Compatibility: Intel LGA1150, LGA1151, LGA1155, LGA1156
• Recommended TDP: Up to 65W
• Heatsink Material: Aluminum Fins, Copper Base
• Fan Diameter: 60 mm
• Fan Speed: 1200 ~ 3500 RPM (PWM controlled)
• Max Airflow: 29.3 CFM
• Min Noise Level: 18.5 dBA
• Max Noise Level: 36.5 dBA
• Bearing Type: Sleeve Bearing
• Fan Connector: 4-Pin PWM
• Rated Voltage: 12V DC
• Rated Current: 0.15A
• Power Consumption: 1.8W
• Color: Black (fins), Copper (base)
• Mounting System: Push-pin
• Thermal Paste: Pre-applied

Recommendations

For optimal performance, ensure your case has adequate airflow. The SST-XE02-TR5B is ideal for HTPCs and compact workstations where space is limited.
