Schwaiger SPS6914R 2-Way F-Splitter Signal Distributor 5-2400 MHz, DC Pass-through, Terracotta

This 2-way F-splitter from Schwaiger distributes satellite, cable TV, and terrestrial signals across a wide frequency range of 5 to 2400 MHz. Its die-cast zinc housing provides excellent shielding of over 100 dB, ensuring clean signal distribution with minimal interference. DC pass-through on all outputs allows remote powering of LNBs or preamplifiers, making it ideal for complex installations.

Advantages

High shielding factor and low insertion loss preserve signal quality across all connected devices. The compact, robust design withstands demanding environments, while the terracotta finish blends discreetly into any setup. DC pass-through eliminates the need for separate power inserters in many satellite configurations.

Suitable for

• Satellite TV distribution to two receivers
• Cable TV and DVB-T antenna splitting
• Radio signal distribution
• Installations requiring DC power pass-through for LNBs

Key specifications

• Frequency range: 5–2400 MHz
• Insertion loss: 4.5 dB (5–860 MHz), 5.0 dB (950–2400 MHz)
• Isolation: 20 dB (5–860 MHz), 18 dB (950–2400 MHz)
• Return loss: 10 dB
• Impedance: 75 Ohm
• Connectors: F-type female
• DC pass-through: Yes, all outputs
• Max DC current: 220 mA
• Max DC voltage: 24 V
• Housing: Die-cast zinc
• Shielding factor: >100 dB

Recommendations

For optimal performance, use high-quality 75-ohm coaxial cables with F-connectors. Ensure all connections are tight to maintain shielding effectiveness. When using DC pass-through, verify that the total current draw of connected devices does not exceed 220 mA.
