Kathrein EMK 17 F Silver Antenna End Socket, 3 Outputs (TV/Radio/SAT), Unicable Compatible, Flush-Mount

The Kathrein EMK 17 F stands out among antenna sockets by combining three separate outputs — TV, radio, and satellite — in a single flush-mounted unit, while its Unicable (SCR) compatibility allows multiple receivers to share one satellite cable without extra hardware. Finished in silver die-cast zinc, it delivers Class A shielding and DC pass-through for LNB power, making it a robust choice for modern home installations.

Highlights

• Three outputs: IEC male (TV), IEC female (radio), and F-connector (SAT)
• Unicable (SCR) compatible for single-cable satellite distribution
• DC pass on SAT output to power LNB directly
• Class A shielding for superior interference rejection
• Flush-mounted design with die-cast zinc housing
• Return path capable (5-65 MHz) for interactive services

In daily use

Installed in a standard flush-mount box, the EMK 17 F provides a clean, professional finish. Connect your TV antenna cable to the IEC male output, a radio tuner to the IEC female socket, and a satellite receiver to the F-connector. With Unicable support, multiple set-top boxes can operate independently from a single satellite feed, reducing cabling complexity. The 2.5 dB attenuation on both TV/radio and SAT paths ensures minimal signal loss, while the 75 Ohm impedance matches standard coaxial systems.

Full specifications

• Product type: Antenna end socket
• Outputs: 3 (TV, radio, SAT)
• TV connector: IEC male (coaxial plug)
• Radio connector: IEC female (coaxial socket)
• SAT connector: F-connector
• TV frequency range: 5 - 862 MHz
• Radio frequency range: 87.5 - 108 MHz
• SAT frequency range: 950 - 2200 MHz
• TV/radio attenuation: 2.5 dB
• SAT attenuation: 2.5 dB
• DC pass: Yes (SAT output)
• Shielding class: Class A
• Mounting type: Flush-mounted
• Colour: Silver
• Unicable (SCR) compatible: Yes
• Return path: 5-65 MHz
• Impedance: 75 Ohm
• Housing material: Die-cast zinc

Final note

The Kathrein EMK 17 F is a reliable, future-proof antenna socket that simplifies multi-service distribution in residential and commercial settings, especially where Unicable technology is required.
