SCHROFF Guide Shoe Accessory Kit 160TE 2mm Red (10 Pack) 24568363

In a busy electronics lab, technicians assembling Eurocard subracks need reliable PCB guidance. The SCHROFF Guide Shoe Accessory Kit provides exactly that: a set of ten red guide shoes, each 2 mm thick, designed to snap into place and securely guide 160 TE plug-in units within standard 19-inch racks. Made from flame-retardant PPO, these guide shoes ensure smooth insertion and extraction of circuit boards, reducing the risk of damage and misalignment in high-density electronic packaging.

Key specifications

• Compatible module width: 160 TE (Teil-Einheit)
• Guide shoe thickness: 2 mm
• Colour: Red
• Quantity per pack: 10 pieces
• Material: PPO (Polyphenylene Oxide), UL 94 V-0 rated
• Mounting type: Snap-in, no tools required
• System compatibility: Eurocard System per IEC 60297-3-101
• Operating temperature range: -40 to +100 °C
• RoHS and REACH compliant

Why choose it

These guide shoes are engineered for precision and durability. The snap-in design speeds up assembly, while the robust PPO material withstands harsh conditions and repeated use. The red colour aids in quick identification and coding within complex systems. Compliance with international standards ensures seamless integration into existing Eurocard infrastructure, making them a trusted choice for professional electronic packaging.

Ideal use cases

• Guiding PCBs in 19-inch subracks for telecommunications equipment
• Securing plug-in units in industrial control systems
• Prototyping and testing Eurocard-based modules in R&D labs
• Maintaining and upgrading legacy electronic enclosures

Good to know

Packaged in bulk for convenience, these guide shoes are an essential accessory for any workshop dealing with modular electronics. They are intended for indoor use and are supplied by nVent Schroff, a leading manufacturer in electronic packaging solutions. Always verify compatibility with your specific card guides and subrack dimensions before installation.
