Satel RK-1K 433 MHz Keyfob Remote Control for ABAX 2/ABAX Alarm Systems

Managing a wireless alarm system often means walking to the keypad to arm or disarm it. The Satel RK-1K keyfob puts that control in your pocket, so you can secure or unsecure the premises from up to 200 meters away in open space. It works with Satel ABAX 2 and ABAX wireless systems, including the ACU-120 and ACU-270 controllers.

Who is it for

Home and business owners who already use a Satel ABAX-based alarm system and want a convenient, pocket-sized way to arm, disarm, or trigger a panic alert without approaching the keypad. Installers also use it to give end users a simple, reliable remote control.

Main features

• Single-button design for simple arming, disarming, or panic activation (function is programmable in the controller).
• Uses KEELOQ® dynamic code rolling encryption to prevent signal capture and replay.
• Operates in the 433 MHz band with FSK modulation for reliable communication.
• Powered by a CR2032 3V lithium battery with typical life up to 3 years.
• Compact and lightweight plastic enclosure, easy to carry on a keyring.
• Environmental class II (EN 50130-5) for indoor and sheltered outdoor use.

Specifications

• Number of buttons: 1
• Wireless frequency: 433 MHz
• Modulation: FSK
• Coding algorithm: KEELOQ® dynamic code
• Power supply: CR2032 3V lithium battery
• Battery life: up to 3 years (typical)
• Wireless range: up to 200 m in open area (depending on receiver)
• Standby current consumption: 0.01 mA
• Transmission current consumption: 10 mA
• Transmission power: 10 mW
• Operating temperature: -10°C to +55°C
• Environmental class: II (EN 50130-5)
• Compatibility: Satel ABAX 2 and ABAX systems (e.g., ACU-120, ACU-270)

Tips

Pair the keyfob with your ABAX controller using the manufacturer's configuration software. If the LED indicator dims or range decreases, replace the CR2032 battery. Keep the keyfob away from water and extreme heat to preserve battery life.
