SATA Cable DeLOCK 85229 0.3m SATA 7-pin SATA 22-pin Black

This cable by DeLOCK enables connection of a device with a 22‑pin SATA interface to a free SATA 7‑pin data port and a free 15‑pin SATA power connector from the power supply. The cable is 0.3 m long, supports SATA III and comes in black with metal clips on the SATA receptacles for a secure click‑in fit.

Advantages

The DeLOCK 85229 combines a 7‑pin SATA data connector with a 22‑pin SATA connector in a short 0.3 m cable, supporting SATA III speeds. Metal locking clips on the connectors ensure reliable mechanical contact and reduce the risk of accidental disconnection. The black finish provides a discreet appearance inside PC cases.

Suitable for

• Connecting 22‑pin SATA devices (e.g., drives or adapters) to a motherboard SATA 7‑pin port
• Internal connections in desktop PC builds or upgrades
• Linking SSDs, HDDs or optical drives that require combined data and power wiring via appropriate power connectors

Key specifications

• Cable type: SATA III
• Cable length: 0.3 m
• Connector 1: SATA 7‑pin (data)
• Connector 2: SATA 22‑pin
• Product colour: Black
• Brand: DELOCK, MPN: 85229, EAN: 4043619852291

How to use

Power off the system and disconnect it from mains power before installation. Insert the 7‑pin SATA connector into a free SATA port on the motherboard until the metal clip clicks. Connect the 22‑pin SATA end to the device’s matching connector, ensuring correct orientation. Reconnect power and boot the system to verify the device is detected.

Recommendations

Use within desktop PC cases or compatible enclosures; avoid excessive bending of the cable and ensure both data and power connections are present and secure before powering the system.
