SATA cable DeLOCK 85228 0.3 m SATA 7-pin SATA 22-pin Black

This Delock SATA cable (model 85228) is a 0.3 m black SATA III lead with a 7‑pin SATA plug on one end and a 22‑pin SATA receptacle on the other. It allows connecting a device that uses a 22‑pin SATA interface to an available 7‑pin SATA port plus a 15‑pin SATA power connector from the power supply, supporting data rates up to 6 Gbps. Metal clips on the SATA connectors ensure a secure, audible click when the cable is fastened.

Advantages

The cable supports SATA III transfer speeds up to 6 Gbps and has a short 0.3 m length for tidy internal routing. Its 22‑pin to 7‑pin configuration makes it suitable for devices that require a combined data/power style connector, while the metal locking clips provide reliable retention in standard SATA ports. The black colour suits most PC interiors.

Suitable for

• Connecting internal SATA drives (HDD/SSD) that require a 22‑pin interface
• Compact PC builds where short cable runs are needed
• Replacing or extending existing internal SATA connections

Key specifications

• Cable type: SATA III
• Cable length: 0.3 m
• Connector 1: SATA 7‑pin (data)
• Connector 2: SATA 22‑pin
• Maximum data rate: 6 Gbps
• Product colour: Black
• Manufacturer MPN: 85228

How to use

Connect the 7‑pin SATA plug to an available SATA data port on the motherboard or controller. Plug the 22‑pin connector into the device that requires the 22‑pin interface, and connect a free 15‑pin SATA power plug from the power supply to provide power. Ensure each connector clicks into place via the metal clips and that the system is powered off when making connections.

Recommendations

Use this short SATA III cable for internal connections inside PC cases; avoid excessive bending or pulling on the cable and keep it clear of fans and heat sources. Verify connector orientation before insertion to prevent damage to the device or motherboard.
