ROLINE LC-LC Multimode OM3 Patch Cable, Duplex, LSZH, Aqua, 1 m

The ROLINE LC-LC Multimode OM3 Patch Cable is a high-performance fiber optic cable designed for reliable data transmission in enterprise networks, data centers, and telecommunications environments. With LC male connectors on both ends, this duplex cable supports 10 Gigabit Ethernet and is backward compatible with existing multimode infrastructure. The LSZH (Low Smoke Zero Halogen) jacket ensures safety in confined spaces, while the aqua-colored jacket provides easy identification.

Advantages

Optimized for OM3 performance, this cable delivers high bandwidth over short to medium distances. The ceramic ferrule connectors ensure low insertion loss and high return loss for signal integrity. The durable LSZH jacket reduces toxic smoke in case of fire, making it ideal for indoor installations.

Suitable for

• 10 Gigabit Ethernet networks
• Fiber Channel storage area networks
• Data center interconnects
• Telecommunications rooms and server racks

Key specifications

• Connector Type: LC Male to LC Male
• Fiber Type: Multimode OM3
• Core/Cladding: 50/125 µm
• Cable Length: 1.0 m
• Jacket Material: LSZH (Low Smoke Zero Halogen)
• Jacket Color: Aqua
• Insertion Loss: < 0.3 dB
• Return Loss: > 30 dB
• Bandwidth (850nm): 1500 MHz-km
• Bandwidth (1300nm): 500 MHz-km
• Maximum Data Rate: 10 Gbps (up to 300m), 40/100 Gbps (shorter distances)
• Standards: TIA/EIA-568-C.3, ISO/IEC 11801, EN 50173
• Operating Temperature: -20°C to 70°C
• Minimum Bend Radius: 30 mm
• Polarity: A-B (Crossed)
• Ferrule Material: Ceramic

Recommendations

For optimal performance, pair this cable with OM3-rated patch panels and transceivers. Ensure proper cable management to maintain bend radius and avoid signal degradation.
