PULSAR DIN Rail Switching Power Supply MEAN WELL HDR-100-24

The PULSAR DIN Rail Switching Power Supply MEAN WELL HDR-100-24 is a high-efficiency, industrial-grade power supply designed for reliable 24V DC output. With a compact plastic housing and DIN rail mounting, it is ideal for control cabinets, automation systems, and industrial applications.

Advantages

This power supply offers a wide input voltage range (85~264VAC), high efficiency up to 90%, and comprehensive protection features including short circuit, overload, and over voltage. Its free air convection cooling ensures silent operation and long service life.

Suitable for

• Industrial automation and control systems
• Building automation and HVAC controls
• PLC and sensor power supply
• Telecommunication equipment

Key specifications

• Output: 24V DC, 4A, 96W
• Input: 85~264VAC (120~370VDC)
• Efficiency: 90%
• Mounting: DIN Rail TS-35/7.5 or TS-35/15
• Protection: Short Circuit, Overload, Over Voltage
• Operating Temperature: -30~+70°C
• Adjustable Output Voltage: 21.6~29V
• Ripple & Noise: 150mVp-p
• Isolation: I/P-O/P 3kVAC, I/P-FG 2kVAC, O/P-FG 0.5kVAC
• Safety Standards: UL 61010-1, TUV EN61010-1, CE, EAC
• EMC Standards: EN55032 Class B, EN61000-3-2, EN61000-4-2,3,4,5,6,8,11

Recommendations

For optimal performance, ensure proper ventilation and use with compatible DIN rail accessories. This power supply is a reliable choice for demanding industrial environments.
