Power Supply Unit Chieftec CTG-650C 650 W

Power Supply Unit Chieftec CTG-650C 650 W
Power Supply Unit Chieftec CTG-650C 650 W
Power Supply Unit Chieftec CTG-650C 650 W
Power Supply Unit Chieftec CTG-650C 650 W
R1,652
The Power Supply Unit Chieftec CTG-650C 650 W is a 650-watt ATX power supply designed for desktop PC systems. It provides a 24-pin ATX motherboard connector, semi-modular cable management, and active cooling via a 120 mm fan. The unit is rated with 80 PLUS efficiency and is built to meet common safe... Read More
Stock Out Of StockNo Stock Code 2553303 Brand CHIEFTEC Model CTG-650C Warranty 2 Years

Shipping & Returns

The Power Supply Unit Chieftec CTG-650C 650 W is a 650-watt ATX power supply designed for desktop PC systems. It provides a 24-pin ATX motherboard connector, semi-modular cable management, and active cooling via a 120 mm fan. The unit is rated with 80 PLUS efficiency and is built to meet common safety and environmental standards, making it suitable for mainstream builds where a balance of power, efficiency and affordability is required.

Advantages

The Chieftec CTG-650C offers reliable continuous output up to 650 W with an overall efficiency around 85%, reducing wasted energy and heat compared with lower-efficiency models. Semi-modular cabling simplifies installation and improves internal airflow by allowing unused cables to be removed. A 120 mm fan provides active cooling with low acoustic signature under normal loads. The matte black housing supports a discreet installation in a variety of case designs.

Suitable for

  • Mainstream desktop PCs for office, home or light gaming use

When it may not be suitable

This PSU may not be suitable for high-end gaming rigs or workstation systems that require peak power beyond 650 W or demand fully modular cabling and multiple high-current PCIe rails for multi-GPU configurations. Users planning extreme overclocking or very power-hungry components should select a higher-rated or more specialized power supply.

Key specifications

  • Total power output: 650 W
  • Efficiency: approximately 85% (80 PLUS certified)
  • Motherboard connector: 24-pin ATX
  • Cabling: semi-modular design
  • Cooling: 120 mm fan (active)
  • Input: AC 230 V, 50 Hz
  • Colour: Black

How to use

Install the PSU in a compatible ATX case following manufacturer guidelines: position the unit to align screw holes, secure it with mounting screws, and connect the 24-pin ATX cable to the motherboard. Attach required peripheral connectors and CPU/PCIe cables from the semi-modular harness as needed. Ensure the AC mains rating matches local supply and connect the power cable. Verify BIOS/UEFI and system stability after first power-up and monitor temperatures and voltages during initial use.

What to consider before purchase

  • Required total system power and headroom for future upgrades
  • Compatibility of available connectors with your motherboard, CPU and GPU
  • Case size and mounting orientation to ensure airflow and fan clearance
  • Importance of semi-modular cabling versus fully modular designs

Recommendations

For typical home, office and light gaming systems, allow 20–30% headroom above estimated continuous system consumption to ensure stable operation and longevity. Keep intake and exhaust airflow unobstructed and perform periodic dust cleaning of the 120 mm fan and PSU vents to maintain cooling efficiency.

Key Highlights
  • Mainstream desktop PCs for office, home or light gaming use
  • 650 W 230 V 50 Hz
  • Total power output: 650 W
  • Motherboard power connector: 24-pin ATX
  • Efficiency: approximately 85% (80 PLUS certified)
  • PC ATX 80 PLUS
  • Motherboard connector: 24-pin ATX
  • Active 12 cm
  • Cabling: semi-modular design
  • Black
  • Cooling: 120 mm fan (active)
  • Input: AC 230 V, 50 Hz
  • Colour: Black
  • Required total system power and headroom for future upgrades
  • Compatibility of available connectors with your motherboard, CPU and GPU
  • Case size and mounting orientation to ensure airflow and fan clearance
  • Importance of semi-modular cabling versus fully modular designs
Specifications
80 PLUS certification
80 PLUS
AC input frequency
50
AC input voltage
230
ATX version
2.3
Cabling type
Semi-Modular
Certification
CE, CB, FCC
Combined power (+12V)
552 W
Combined power (+3.3V)
130 W
Combined power (+5V)
130 W
Combined power (+5Vsb)
15 W
Combined power (-12V)
3.6 W
Compliance certificates
RoHS
Cooling type
Active
CPU P4 connector (4-pin)
1
CPU power connectors (8-pin)
1
Depth
140 mm
Efficiency
85 %
EPS power connector (8-pin)
Yes
Fan diameter
120 mm
Fan location
Top
Floppy drive power connector
2
Harmonized System (HS) code
84733020
Height
87 mm
Input current
6
Max output current (+12V1)
300 A
Max output current (+12V2)
30 A
Max output current (+3.3V)
22 A
Max output current (+5V)
22 A
Max output current (+5Vsb)
3 A
Max output current (-12V)
0.3 A
Maximum input current (@110V)
12 A
Mean time between failures (MTBF)
100000 h
Motherboard power connector
24-pin ATX
Number of fans
1 fan(s)
Number of SATA power connectors
6
Package type
Box
PCI Express power connectors (6+2 pin)
2
Peripheral (Molex) power connectors (4-pin)
4
Power factor
0.9
Power Factor Correction (PFC) type
Active
Power protection features
Under current, Under voltage, Over current, Over voltage, Overheating, Overload, Short circuit
Power supply unit (PSU) form factor
ATX
Product colour
Black
Purpose
PC
Total power
650 W
Width
150 mm

Leaflet

Open Leaflet

Document

Open Document

Leaflet

Open Leaflet
Price history over the last 6 months
Power Supply Unit Chieftec CTG-650C 650 W
Current
R1,652
Lowest
R1,446
Highest
R1,652
Change 24H
+R162   +11%
Week
+R206   +14%
Month
+R206   +14%

Independent reviews by tech media

eteknix.com

Verdict: Chieftec's A-80 power supply does exactly what it says on the tin: great performance without a significant price tag. Even though we are not 100% sure of the OEM used I can still say with confidence that the Chieftec A-80 650W is a quality power supply. I...

Pros
  • Excellent voltage regulation
  • Quiet operation under most loads
  • Good ripple suppression
  • High PFC
  • Low price
  • Betters its 80 Plus Bronze certification
Cons
  • Not the nicest exterior (of the cables or unit)
  • Could do with more PCIe
  • 2 year warranty is a little short
Read the full review at eteknix.com →
