Power Adapter MEAN WELL SCWN03C-15 3W 15V 36-72V Input

The MEAN WELL SCWN03C-15 is a compact DC-DC regulated single output converter that accepts a wide input range of 36–72 VDC and provides a stable 15 VDC output at up to 0.2 A (3 W). Housed in a DIP through-hole package, the module offers 3000 VDC input-to-output isolation and complies with RoHS environmental requirements.

Advantages

The SCWN03C-15 delivers a regulated 15 V output with low footprint and through-hole mounting for easy PCB integration. Its wide 36–72 V input range accommodates variable supply conditions, while 3000 VDC isolation enhances safety between input and output circuits. RoHS compliance ensures restricted hazardous substances in manufacturing.

Suitable for

• Industrial control and automation modules
• Telecommunications equipment with high-voltage buses
• Embedded systems and single-board computers requiring 15 V rail
• Applications needing isolated low-power supplies

Key specifications

• Manufacturer: MEAN WELL
• Model (MPN): SCWN03C-15
• Input voltage: 36–72 VDC
• Output voltage/current: 15 VDC at 0.2 A (3 W)
• Isolation: 3000 VDC input-to-output
• Package: DIP through-hole
• Compliance: RoHS
• EAN: 4021087041799

How to use

Mount the SCWN03C-15 into a compatible PCB using its DIP through-hole pins. Connect the input terminals to a DC source within 36–72 V and verify polarity before powering. Use the 15 V output to feed the target circuit, observing the 0.2 A maximum current rating. Ensure proper clearance and mounting to maintain the specified isolation and thermal conditions.

Recommendations

Operate the converter within its specified input range and load limits. Provide adequate board spacing and grounding to preserve the 3000 VDC isolation. For long-term reliability, avoid continuous operation at maximum load and follow the manufacturer's guidelines for thermal management.
