Power Supply Unit MEAN WELL HDR-15-15 15W Black Stainless Steel

The MEAN WELL HDR-15-15 is an ultra-slim DIN rail AC‑DC power supply delivering 15V DC at 1A with a 15W output. It accepts a wide AC input range of 85–264VAC and is certified to IT AV EN/UL/IEC 62368-1. Housed in a black and stainless steel case with compact dimensions (17.5mm W × 54.5mm D × 90mm H), it provides basic protections for safe, continuous operation.

Advantages

The unit offers a wide input voltage range for global compatibility, compact DIN-rail mounting for space-saving installation, and built-in protection against overvoltage, overload and short circuit. Its slim profile and metal casing support reliable mounting in control cabinets while meeting safety certification standards.

Suitable for

• Industrial control panels and automation equipment
• Building management and HVAC control modules
• Small instrumentation and monitoring devices
• General DIN-rail installations requiring a 15V DC supply

Key specifications

• Model: MEAN WELL HDR-15-15 (HDR-15 series)
• Input voltage: 85–264VAC
• Output: 15V DC, 1A (15W)
• Mounting: DIN rail
• Dimensions: 17.5mm × 54.5mm × 90mm (W × D × H)
• Protection: overvoltage, overload, short circuit
• Standards: IT AV EN/UL/IEC 62368-1
• Construction: black and stainless steel housing

How to use

Mount the HDR-15-15 on a standard DIN rail inside a suitable enclosure. Connect the AC input within the specified 85–264VAC range to the input terminals and connect the 15V DC output to your load, observing correct polarity. Ensure the unit is properly grounded and that the total connected load does not exceed 1A. Follow local wiring regulations and safety practices when installing.

Recommendations

Place the power supply in a ventilated enclosure and avoid mounting near heat sources. Verify that upstream fusing and wiring are rated for the input voltage and that the load stays within the rated 15W to maintain reliable operation.
