Power adapter MEAN WELL MPM-10-24, 10 W, input 80–264 V, output 24 V, RoHS

MEAN WELL MPM-10-24 is a compact AC–DC single-output power adapter offering a fixed 24 VDC output at up to 0.42 A and 10 W total power. With a wide input range of 80–264 VAC, this encapsulated module is intended for low-power industrial and commercial applications, control panels, instrumentation and embedded systems. Its through-hole PCB mounting and a depth of 45.7 mm make it suitable for space-constrained assemblies; the unit is RoHS compliant and uses reinforced isolation with two MOPP barriers for safety in medical-grade designs.

Advantages

The adapter provides stable 24 V output with low power loss in a small 45.7 mm depth package weighing approximately 80 g, enabling compact system layouts. Wide-range input (80–264 V) allows operation in varied mains environments without additional front-end converters. Encapsulated construction offers mechanical protection and electrical insulation while two MOPP-level isolation stages support enhanced safety requirements for equipment that needs medical isolation separation. PCB through-hole format simplifies secure mounting in printed-circuit assemblies.

Suitable for

• Control panels and industrial automation modules
• Instrumentation and measurement devices
• Embedded systems and low-power communication equipment
• Medical devices requiring reinforced isolation (where two MOPP applies)

Key specifications

• Input voltage range: 80–264 VAC
• Output: 24 VDC nominal, 0.42 A maximum
• Rated power: 10 W
• Mounting: PCB through-hole
• Protection: encapsulated construction for mechanical and electrical protection
• Isolation: two MOPP (reinforced working voltage separation)
• Compliance: RoHS
• Dimensions: depth 45.7 mm; weight approximately 80 g

How to use

Install the module on the host PCB using the through-hole leads and ensure secure solder joints and mechanical support. Connect the AC input within the specified 80–264 VAC range and route the 24 VDC output to the load, observing polarity and current limits. Provide adequate creepage and clearance on the PCB according to the system safety requirements and maintain proper thermal conditions; allow airflow or heatsinking as required by surrounding components. Verify isolation and grounding arrangements in the final assembly to preserve the two MOPP safety separation.

Recommendations

For reliable long-term operation, avoid sustained operation near the maximum output current and ensure the operating ambient temperature stays within the module's rated range. Follow applicable medical and industrial standards for isolation, clearance, and creepage when integrating this adapter into equipment that requires reinforced safety barriers.
