Polymaker Fiberon PA6-CF20 Carbon Fiber Nylon Filament 1.75mm Black 0.5kg

The Polymaker Fiberon PA6-CF20 is a high-performance carbon fiber reinforced nylon filament designed for industrial applications requiring exceptional strength, stiffness, and heat resistance. With 20% carbon fiber content by weight, this filament delivers outstanding mechanical properties and dimensional stability, making it ideal for functional prototypes, tooling, jigs, fixtures, and end-use parts.

Advantages

High strength and stiffness comparable to metal parts; excellent heat resistance with HDT of 150°C; low warp for reliable printing; high-quality surface finish; compatible with hardened steel nozzles.

Suitable for

• Functional prototypes and end-use parts
• Tooling, jigs, and fixtures
• Automotive and aerospace components
• Industrial machinery parts

Key specifications

• Material: PA6-CF (Nylon 6 Carbon Fiber)
• Filament Diameter: 1.75 mm
• Net Weight: 0.5 kg
• Colour: Black
• Print Temperature: 280 - 300 °C
• Bed Temperature: 25 - 50 °C
• HDT @ 0.45 MPa: 150 °C
• Tensile Strength (X-Y): 100 MPa
• Flexural Modulus: 6000 MPa
• Density: 1.20 g/cm³
• Glass Transition Temperature: 70 °C
• Printing Speed: 30 - 60 mm/s
• Spool Material: Recycled Cardboard

Recommendations

Use a hardened steel or wear-resistant nozzle. Dry filament before use (moisture sensitive). Store in a dry environment. Ensure proper ventilation during printing.
